FOWLHOUSE
1.51W x 1.39D x 1.99Hm
Fowl House Series
Congratulations on purchasing your new Pinnacle fowl house. Before assembling, we recommend
you read the instructions thoroughly. Your new fowl house comes with pre-drilled holes to make
assembly quicker. We recommend you assemble it using a trestle table or sawhorses and planks.
This will ensure that you are working off the ground and make it easier for you.
Assembly of this fowl house is a two-person job and should not be attempted in windy conditions.
Tools required: Drill, measuring tape, Phillips-head screw driver, rivet gun, rubber mallet, sturdy ladder, shifting spanner, 2 saw horses, 3mm
steel drill bit, 4mm steel drill bit and a 10mm masonry drill bit.
Assembly instructions
www.pinnacle.net.au
Check out our
shed building
tips on Youtube!
AU: 1800 349 776
NZ: 09 276 4071
Advertisement
Related Manuals for Pinnacle Fowl House Series
Summary of Contents for Pinnacle Fowl House Series
- Page 1 AU: 1800 349 776 NZ: 09 276 4071 Congratulations on purchasing your new Pinnacle fowl house. Before assembling, we recommend you read the instructions thoroughly. Your new fowl house comes with pre-drilled holes to make assembly quicker. We recommend you assemble it using a trestle table or sawhorses and planks.
- Page 2 FOWLHOUSE 1.51W x 1.39D x 1.99Hm Dimension overview: Outer base dimensions 1515 x 1395 mm Inner base dimensions 1470 x 1350 mm Wall height 1800 mm Peak height 1995 mm Roof width 1615 mm Door opening dimensions 1740 x 746 mm...
- Page 3 Build your fowl house in 7 easy steps! Step 1: Check all parts against the component list Step 2: Assemble the rear wall panels Step 3: Assemble the side wall panels Step 4: Assemble the roof panels Step 5: Assemble the front wall panel Step 6: Assemble the front door Step 7: Fit the panels together Warning: Do not assemble this fowl house on a windy day.
- Page 4 FOWLHOUSE 1.51W x 1.39D x 1.99Hm Step 1: Check all parts against the component list Lay out all parts with number facing outwards and check off against parts list. Part Picture Description Component Location QTY Check Sheet Sheet 1800x770mm Rear wall Sheet Sheet 1800x708mm Side wall...
- Page 5 Part Picture Description Component Location QTY Check Channel Channel 1508mm Rear wall Channel Channel 1508mm Rear wall Channel Channel 1508mm Front Channel Channel 1508mm Front Roof side Channel Channel 1391mm wall Channel Channel 1391mm Roof Channel Channel 1391mm Side wall Channel Channel 1391mm Side wall...
- Page 6 Signature: _________________________________________ In the unlikely event that you find you are missing a part, Australian customers please contact Pinnacle on 1800 349 776. New Zealand customers please contact Harco (Harkness & Young Ltd) on: 09 276 4071. A copy of proof of purchase may be requested.
- Page 7 Fowl house overview:...
- Page 8 FOWLHOUSE 1.51W x 1.39D x 1.99Hm Step 2: Assemble the rear wall panels For easier assembly of your fowl house use sawhorses with timber studs as per diagram below (timber needs to be the same length as the fowl house (1.5 M)) or alternatively, a trestle table. Place 2 x part S75 (sheets) on your worktable and join together with the self-tapping screws as per the diagram below.
- Page 9 Assemble the rear wall panels (continued) Step 2: NOTE: All screws marked with a cross should not be fixed at this stage.
- Page 10 FOWLHOUSE 1.51W x 1.39D x 1.99Hm Assemble the side wall panels Step 3: Place parts S77 & S79L (sheets) on your worktable and tap or slide on part 36F (top channel) and part 36A (bottom channel). Make sure the small lip of the channels is always facing out. This ensures rainwater cannot build up inside your fowl house. Once the top and bottom channels have been fixed, attach the channel (C121) above the mesh on part S79L (sheet) with the provided 3 x 10mm rivets.
- Page 11 Assemble the side wall panels (continued) Step 3: Now repeat for other side wall. FIX WITH 16MM SCREWS FIX WITH 3 X 10MM RIVET...
- Page 12 FOWLHOUSE 1.51W x 1.39D x 1.99Hm Assemble the roof panel Step 4: Place 1 x part S81 (sheet) and 1 x part S82 (sheet) on your worktable and join together with the self-tapping screws as per the diagram below. 2 pre-punched holes to this end of each sheet with part 36A (channel) Now tap or slide 1 x part 36C and 1 x part 36A (channels) onto the sheeting and fix them to the top and bottom with...
- Page 13 Step 5: Assemble the front wall panels Place part S80 (front wall sheet) on the worktable then fit parts 20T (top channel) and 20U (bottom channel) to the front wall sheeting and fix with self-tapping screws. Secure the iron mesh by riveting part C121 (channel) onto part 20T (top channel). It’s recommended you fix the back part first, then the front.
- Page 14 FOWLHOUSE 1.51W x 1.39D x 1.99Hm Step 5: Assemble the front wall panels (continued) Fit parts 42 (jamb), J36 (jamb) and part 23 (bottom channel) to the front wall and fix with self-tapping screws. Make sure the joints are fixed as per the below diagrams. NOTE: All screws marked with a cross should not be fixed at this stage.
- Page 15 Assemble the front door Step 6: Fix part D33 (pre-assembled door) to the front wall panel using a rivet gun and the provided 4.0 x 10mm rivets. FIX WITH 4 X 10MM RIVET...
- Page 16 FOWLHOUSE 1.51W x 1.39D x 1.99Hm Assemble the front door (continued) Step 6: Now fix part 70 (pad bolt) using the pre-drilled holes with the 10mm self-tapping screws or 3 x 10mm rivets provided. FIX WITH 10MM SCREWS FIX WITH 3 X 10MM RIVET...
- Page 17 Fit the panels together Step 7: Attach the two side walls to the back wall, then fit the front wall by fixing 2 x parts Z34, 1 x part Z35 and 1 x part Z36 (corner bracing) Fix all of these components together using the provided self-tapping screws as per the diagram below.
- Page 18 FOWLHOUSE 1.51W x 1.39D x 1.99Hm Fit the panels together (continued) Step 7: Once all 4 panels are fixed together attach 2 x part SG28 (Gable L/H) and 2 x part SG27 (Gable R/H) to the front and back panels with the provided self tapping screws as per diagram below.
- Page 19 Fit the panels together (continued) Step 7: Start assembling the roof by fixing part 93 (ridge beam) to part 92 (gable cap connector) and then fix to one of the assembled roof panels from step 4. CHANNEL TYPE 36A THIS END CHANNEL TYPE 36C THIS END...
- Page 20 FOWLHOUSE 1.51W x 1.39D x 1.99Hm Fit the panels together (continued) Step 7: Once half the roof is fixed together, place on top of fowl house and slide the other assembled roof panel from step 4 into place and fix from underneath.
- Page 21 Fit the panels together (continued) Step 7: Fix 4 x part SL08 (lips) to the front and back ends of the roof panels with the provided 16mm self tapping screws. Now place 2 x part E1 (logo cap) to the front and back peaks and fix with the provied 16mm self tapping screws as per diagram below. FIX IT WITH 16MM SELF TAPPING SCREWS FIX IT WITH 16MM...
- Page 22 FOWLHOUSE 1.51W x 1.39D x 1.99Hm Fit the panels together (continued) Step 7: A bolt down kit can be purchased from your local Bunnings store and attached to this fowl house. Please refer to diagram below for installation. BOLT NUT WALL SHEET STEEL ANGLE SLAB...
- Page 23 Process of claiming Warranty: To make a claim under the Warranty within the Warranty Period, you will need to contact the manufacturer directly by phone or email: Australian Customers please contact Pinnacle Hardware on: Claims Department contact number: 1800 349 776 Claims Department email: support@pinnacle.net.au...
- Page 24 FOWLHOUSE 1.51W x 1.39D x 1.99Hm – Where assessment is required in case of replacing or repairing the product, the manufacturer will appoint an assessor within 10 working days to identify the alleged defect. The manufacturer will bear the repair costs by appointing a local tradesman. The manufacturer may choose to replace the product if the repair or the cost of repair is not feasible.
