- Page 1 AiroDoctor Air Purifier User Manual WAD-M20 Please read this manual completely before using this product...
-
Page 2: Table Of Contents
Dear Customer, Thank you for purchasing our AiroDoctor. In order to facilitate the installation and use of this product, we recommend that you carefully read this manual and keep it stored safely. To ensure that you always enjoy fresh air, use this manual for qualified and standardized installation, proper use, and maintenance. -
Page 3: Installation/Use Instructions
INSTALLATION/USE INSTRUCTIONS ▪ Do not place in direct sunlight, facing air conditioner vents, or heated places. It may cause the unit to warp, deteriorate, discolor, or malfunction. ▪ Do not place near TVs or radios. This may distort images or produce noise. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS ▪ Do not pick up or move the product while it is running. When moving or storing, do not pull the power cord. This may cause a short circuit or do internal damage to the power cord. This may lead to a fire or electric shock. ▪... - Page 5 IMPORTANT SAFETY INSTRUCTIONS ▪ Make sure the remote is placed somewhere children cannot reach to avoid unintended damage. ▪ Use the handle on the side of the main body when moving the product. Forcing other parts to pull can cause product damage and injury.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS ▪ Please unplug the cord using the plug insulator. - Pulling the power cord to unplug it may cause damage to the power cord, electrical cord, electrical shock, short circuit, or fire. ▪ Should any of the following circumstances arise, please turn off the machine power immediately and contact the service department: - A switch does not work.
-
Page 7: Components
COMPONENTS Air Outlet Indicator Light of Air Quality Handle (On Both sides) Front Cover Air Inlet (On Both sides) Display Screen Light Sensor Operation Touch Panel... -
Page 8: Features
FEATURES Key Features ▪ Using eco-friendly UV LED photocatalytic technology ▪ Excellent Sterilization & Deodorization Effect with LED ▪ Secondary product zero due to air pollutant removal ▪ No Ozone ▪ 99.9% Removes odor, harmful gas and bacteria by decomposition ▪... -
Page 9: Installing The Product
INSTALLING THE PRODUCT Installing the Filter 1. Removing the Front Cover 4. There are differences between the inside (Use both hands to pull) and the outside of the absorption filter (Carbon Filter and HEPA Filter). ※ The side with a handle should be placed outwards. - Page 10 INSTALLING THE PRODUCT Functional Description Icon Name Description When the product is plugged in and on standby, “POWER” button works to turn on the product. After this button being touched for the second time, the product turns to standby state. (The icon is red when Power ON/OFF standby and green when on) If you press the power button on the operation panel while the...
- Page 11 INSTALLING THE PRODUCT Functional Description Icon Name Description This product has a regular reminding function of filter replacement, which works every 320 hours and 1500 hours, the indicator light on the panel will flash to inform users to clean the filter after cleaning, press the “RESET”...
-
Page 12: Cleaning & Maintenance
CLEANING & MAINTENANCE ※ Please proceed with the power plug before cleaning & maintenance of the product. ▪ Please use a soft cloth to remove stains and dirt from the product body. For stains that cannot be gently wiped off, apply on an appropriate amount of water or diluted neutral detergent and wipe off. -
Page 13: Filter Replacement
FILTER REPLACEMENT ※ You may need to replace filters sooner depending on where and how you use the appliance (such as a household with a large smoking population or areas with higher air pollution). Since the filter is a consumable, it needs to be purchased separately and replaced if it is over its lifetime during the warranty period (such as when the air clean efficiency is noticeably lower). -
Page 14: Troubleshooting
TROUBLESHOOTING ※ Before you request a complaint for a breakdown, please check the following troubleshooting instructions and contact the retailer where you purchased the product if the issue is not resolved. Malfunction Inspect / How to fix 1. Make sure the power plug is fully inserted into the outlet, then press the power button to use it. -
Page 15: Specifications
SPECIFICATIONS Product Name AiroDoctor Air Purifier Model Name WAD-M20 Max. Room Size 200 m CADR 480 m (Clean Air Delivery Rate) Noise Level (Max.) 55 dB Pre Filter, Integrated (Carbon+HEPA) Filter, Filter Type UV LED Photocatalytic Filter HEPA Filter Grade... - Page 16 KOREA Carsten Hermann Authorized person: Description of items: • Product type: AiroDoctor UV-LED Photocatalytic Air Sterilizer • Series: WAD-M20 Moreover, the product(s) meet the compliance with another, also applicable EC- Directives: • Low Voltage EC Directive (2006/95/EC) of December 12th, 2006 •...
- Page 17 For perfect air AiroDoctor and Airo.Health are trademarks of: ScreenSource GmbH Köthener Str. 8 06779 Raguhn-Jessnitz GERMANY Telephone: +49 (0) 30 39886850 E-Mail: europe@airodoctor.com Web: www.airodoctor.com Commercial Register: District Court Stendal, HRB 24520 VAT Information: Sales tax identification number according to § 27 a sales tax law: DE311493511 ©...
