Mosquito Trap
Instruction Manual
V1.v.1114
Mosquito Control
Biogents® Suna™
Advertisement
Table of Contents
Related Manuals for Biogents Labitems Suna
Summary of Contents for Biogents Labitems Suna
- Page 1 Labitems 8-1-293/E/1, Plot no 70, Dwaraka Nagar Colony, Shaikpet, Hyderabad. Telangana. Land mark: Opposite to OASIS School, 500008 Phone: 080-48618582 Mobile: 93985-49095 | 97050-26100 Mosquito Control WEB: https://www.labitems.co.in EMAIL: info.labitems@gmail.com Mosquito Trap Instruction Manual V1.v.1114 Biogents® Suna™...
- Page 2 2 EN...
-
Page 3: Table Of Contents
Table of contents How does the trap work ..................Product components . -
Page 4: How Does The Trap Work
How does the trap work The patented Biogents Suna trap is specifically developed for use against malaria mosquitoes. Ventilator Trap bottom Shutter preventing mosqui- toes from escaping Odor plumes Air current to suck the mosquitoes in plume The combination of Advantages: •... -
Page 5: Product Components
Product components Trap lid Bottom cover of trap with incorporated ventilator Tripod assembly Large catch bag Small catch bag for monitoring purposes Intake funnel with shutter (attached to the bottom cover) * emitter spout (attached to the bottom cover) Battery connection * tube connection *The CO source is not included in the contents and must be sourced separately... -
Page 6: Selected Features In Details
Selected features in detail The surface of the bottom cover is riddled with small holes that direct the air plumes out of the trap. The shutter mechanism prevents the caught mosquitoes from escaping in case power supply fails for any reason. Shutter gate closed Shutter gate open The power supply cable can be directed... -
Page 7: Assembling The Trap
Assembling the trap Fix the hanging tripod assembly with the three rounded ends onto the bottom cover with the incorporated ven- tilator by inserting them into the side openings (F1). Attach the large catch bag to ventilator. Fix the catch bag onto the hanging tripod assembly by placing the top loop onto the top hook (F2) and the three side loops on the bottom hooks (F2). - Page 8 Guide the power cable either through the lid and the upper part of the hanging assembly (F6) or laterally through the bottom cover. Attach the intake funnel and the CO emitter nozzle onto the bottom cover of the trap (F7). If you use the small catch bag, attach the intake funnel together with the small catch bag onto the bottom cover.
-
Page 9: Administering The Carbon Dioxide
10 kg gas cylinder which is also used in restaurants for draft beer and soda. ATTENTION: A current list of distributors with competitive renting conditions can be found at www.biogents.com Optional: attaching the pressure reducing regulator onto the CO... -
Page 10: Power Supply And Electricity
3. Place the lure inside the trap (F15). of human skin and releases a mixture of several compounds for up to five months. We also offer the Biogents Sweetscent attractant which is similar to the BG-Lure, but only lasts two months and is ideal for indoor use. Both pro-... -
Page 11: Maintenance And Care
Do not use any pointy or rough the lure dispenser needs to be exchanged (BG-Lure objects to clean the trap. after five months, Biogents Sweetscent after six to eight weeks) • From time to time, check and make sure that: the air flow through the catch bag is obstructed by •... - Page 12 When changing the catch bag, household gloves should be worn. Changing the catch bag: While the ventilator is still running lift the lid and hang it on a hanger (F16). Release the loops on the large catch bag from the hooks on the tripod assembly (F17).
- Page 13 Remove the large catch bag from the ventilator. Make sure to keep the catch bag within the suction current of the ventilator (F19). Pull the cord on the large catch bag shut to close the catch bag (F20). Place the closed catch bag in the sun or in a freezer for at least 2 hours to kill the mosquitoes.
-
Page 14: Positioning Of The Trap
Positioning of the trap • The correct placement of the trap is an important factor that The trap should also be positioned close to mosquito heavily influences its effectiveness. breeding sites such as various kinds of temporary stag- Outdoor use: nant water ranging from small lakes to collections of Position the trap in a location that is sheltered from wind, rain water in rain barrels or old tires. -
Page 15: Technical Data
DIRECTIVE 2009/125/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 21 October 2009 establishing a framework for the setting of ecodesign requirements for energy-related products The Technical Construction File required by this Directive is maintained at the corporate headquarters of Biogents AG, Wei- ßenburgstr. 22, 93055 Regensburg, Germany. -
Page 16: Contact
Hyderabad. Telangana. Biogents AG Land mark: Opposite to OASIS School, 500008 Weißenburgstr. 22 WEB: https://www.labitems.co.in 93055 Regensburg EMAIL: info.labitems@gmail.com Germany Phone: 080-48618582 www.biogents.com Mobile: 93985-49095 | 97050-26100 For more information about the Suna trap please contact us at biogents@biogents.com 16 EN...
