52059454
1.800.561.8187
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS
Read and understand all of the instructions and safety information in this
manual before operating or servicing this tool.
Lea y entienda todas las instrucciones y la información sobre seguridad
que aparecen en este manual, antes de manejar estas herramientas o
darles mantenimiento.
Lire attentivement et bien comprendre toutes les instructions et les
informations sur la sécurité de ce manuel avant d'utiliser ou de procéder à
l'entretien de cet outil.
© 2011 Greenlee Textron Inc.
www.
TG-2000
Infrared and Contact
Thermometer
Termómetro infrarrojo
y de contacto
Thermomètre infrarouge
et à contact
.com
information@itm.com
4/11
Advertisement
Table of Contents
Related Manuals for Textron Greenlee TG-2000
Summary of Contents for Textron Greenlee TG-2000
- Page 1 Lire attentivement et bien comprendre toutes les instructions et les informations sur la sécurité de ce manuel avant d’utiliser ou de procéder à l’entretien de cet outil. 52059454 © 2011 Greenlee Textron Inc. 4/11 1.800.561.8187 information@itm.com www. .com...
-
Page 2: Purpose Of This Manual
Keep this manual available to all personnel. Do not discard this product or throw away! All specifications are nominal and may change as design improvements occur. Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. -
Page 3: Important Safety Information
TG-2000 Important Safety Information SAFETY ALERT SYMBOL This symbol is used to call your attention to hazards or unsafe practices which could result in an injury or property damage. The signal word, defined below, indicates the severity of the hazard. The message after the signal word provides information for preventing or avoiding the hazard. - Page 4 Important Safety Information Electric shock and fire hazard: Do not expose this unit to rain or moisture. Do not use the unit if it is wet or damaged. Use this unit for the manufacturer’s intended purpose only, as described in this manual. Any other use can impair the protection provided by the unit.
- Page 5 TG-2000 Important Safety Information Burn hazard: Avoid contact with the probe until it has cooled. The thermocouple probe may remain hot for several minutes after making a temperature measurement. Do not exceed the temperature rating of the thermocouple probe. Consult the manufacturer’s specifications for the selected probe.
- Page 6 Important Safety Information CE Certification This instrument conforms to the following standards: EN50081-1:1992, Electromagnetic Emissions EN50082-1:1992, Electromagnetic Susceptibility Readings may be affected if the unit is operated with a radio frequency electromagnetic field of approximately 3 volts per meter, but the performance of the instrument will not be permanently affected.
- Page 7 TG-2000 Identification 1. Display 2. Decrease button and °C/°F selector 3. Mode selector 4. Increase button and Lock button 5. Probe jack 6. Trigger 7. Battery compartment door 8. Lens 9. Lasers Display Icons 11. Lock mode indicator 12. Full battery indicator 12A.
-
Page 8: Using The Features
Using the Features Basic Features To turn the laser on or off: Press and hold the trigger, and then momentarily press the button. To turn the backlight on or off: Press and hold the trigger, and then momentarily press the button. - Page 9 TG-2000 Distance from Target Thermometers measure the surface temperature of an object by sensing its emitted, reflected, and transmitted energy. The sensor collects this energy from the area being measured (spot size). The spot size varies as the distance to the target changes. The farther the distance from the area being targeted, the larger the spot size.
-
Page 10: Operation
Operation LASER RADIATION DO NOT STARE INTO BEAM CLASS 2 LASER PRODUCT LASER RADIATION–DO NOT STARE INTO BEAM CLASS II LASER PRODUCT Max. Output <1 mW, CAUTION–CLASS 2 Wavelength: 635-660 nm LASER RADIATION WHEN OPEN Complies with 21 CFR, Chapter 1, subchapter J 1. -
Page 11: Troubleshooting
TG-2000 Operation (cont’d) Troubleshooting Code Problem Action Thermometer has been exposed to rapid Allow at least 30 minutes for thermometer temperature change. to stabilize at new ambient temperature. Ambient temperature is outside operating Operate thermometer within limits in the limits (refer to “Specifications”). “Specifications”... -
Page 12: Typical Measurements
Typical Measurements Electronics Power Distribution HVAC Minimum width of line is 25 mm (1") for accurate reading Non-insulated line 1.800.561.8187 information@itm.com www. .com... - Page 13 TG-2000 Emissivity Emissivity is the ability of an object to emit infrared energy. Most objects or surfaces have an emissivity value of about 0.95. Some objects, such as polished or shiny metallic surfaces, may have much lower emissivity. Using an infrared thermometer to measure the temperature of such objects will produce inaccurate results.
- Page 14 Emissivity (cont’d) Common Emissivities Material Emissivity Material Emissivity Aluminum 0.30 Iron* 0.70 Asbestos 0.95 Lead* 0.50 Asphalt 0.95 Limestone 0.98 Basalt 0.70 0.94 Brass* 0.50 Paint 0.93 Brick 0.90 Paper 0.95 Carbon 0.85 Plastic** 0.95 Ceramic 0.95 Rubber 0.95 Concrete 0.95 Sand 0.90...
-
Page 15: Specifications
* For improved accuracy, allow unit 30 minutes to adjust to large change in temperature. Statement of Conformity Greenlee Textron Inc. is certified in accordance with ISO 9001 (2000) for our Quality Management Systems. The instrument enclosed has been checked and/or calibrated using equipment that is traceable to the National Institute for Standards and Technology (NIST). -
Page 16: Maintenance
Maintenance Electric shock hazard: Do not attempt to repair this unit. It contains no user-serviceable parts. Failure to observe this precaution may result in injury and can damage the unit. Battery Replacement 1. Pivot the top of the door down and away from the handle. 2.
