- Page 1 LINX-21x Automation Server, BACnet Installation instructions Instructions de montage Instruzioni di montaggio Montageanweisung Instrucciones de montaje Montagevoorschrift Monteringsanvisning max 50º C min 0º C 10 - 90 % 0,250 kg LOYTEC...
- Page 2 DIN TS35 0.2 - 2.5 mm 3 poles: Weidmüller BLZP 5.08/06/180...
- Page 3 BACnet/IP Ethernet POWER LINK STATUS RESET Serial Terminal / M-Bus BBMD RS-485 Ethernet POWER 4 5 6 15 16 17 10/100Base-T (RJ45) 12-35 VDC EIA-485 12-24 VAC BACnet MS/TP or Modbus Connectors Status LEDs EIA-485 4 Input GND A OFF PLC not running MS/TP 5 Input + (B) non-inverting input...
- Page 4 1 2 3 4 5 6 7 Serial Port OFF Terminal Mode M-Bus Mode Factory default, do not change! OFF OFF ON OFF OFF OFF MAC address of Ethernet port LOYTEC electronics GmbH Date Code LINX-210 MAC1 000AB001285B MADE IN EC W12/2010...
