- Page 1 WARNING The water heater must be used in reliable ground connection. SANITARY WATER RESERVER Installation & Operation Manual...
- Page 2 The manual provides many important security measures for you to use the air source water heater. Please read the manual carefully before use the unit. All safety measures have safety warnings. The followings are the meanings of each warning: ATTENTION There will be potential danger for you and others.
-
Page 3: Table Of Contents
1.Safety Precaution Contents WARNING Contents Household electricity must have reliable grounding. Household electricity leakage protection device must be installed. Do not tear down any permanent instructions, labels or parameters panel of the heater. 1. Safety Precaution 2.Choice of installation site 3.Safety Caution Specs WARNING... -
Page 4: Choice Of Installation Site
2.Choice of installation site 3.Safety caution Choice of the installation site of the unit Safety Precautions： The water heater can be installed indoors or outdoors. Recommend the installation in the 1） balcony. If installed outdoors, please make the rain proof measures. To prevent the users and others from the harm of this unit, avoid damage on the unit or other Choose the place that there are no direct sunlight and other heat radiating. -
Page 5: Safety Caution
3. Safety Caution 3.Safety Caution Overheat protector recovery Overheating protector will disconnect the power supply automatically when the temperature of the water in the tank is too high which may be caused by the malfunction of the unit. It has t o The unit CANNOT be installed near the flammable gas. -
Page 6: Specs
4. Specs 4. Specs 3.Principium of water heater 1.Appearance Air inlet Air outlet System diagram: High temp. Controller Hot water Air from outside Tank Duct Air fin Optional discharged Cold air exchanger air space needed Water supply Low temp. Tank Throttling Liquid device... -
Page 7: Dimension
4.Specs 4. Specs 5. Performance parameter 4.Dimensions Model WSW2.5-300 L unit：mm Heating capacity model Water tank capacity Model WSW2.5-300 L dimension Power input 0.89 1976 Running current 1467 Power supply 230V~/50Hz 1212 Φ640 Compressor Number Compressor rotary Rated outlet water Temp. -
Page 8: Function Presentation
6. Installation and Connecting Pipe 5. Function presentation Function presentation 1. Installation sketch map Unit：mm Air conditioning Air outlet could be connected to the air duct to bring fresh cool air into the rooms. Air duct If this measure is carried out, a reversing valve should be installed in the air duct to make the cool air blows to outdoors in winter. -
Page 9: Choose The Suitable Unit
6. Installation and Connecting Pipe 6. Installation and Connecting Pipe 2. Choose the suitable unit 4 Installation position In order to save the energy, please choose the suitable unit. (1) Waste heat is useful heat The standard hear exchanger of the hot-water heat pump enables direct connection to a People second heat generator, e.g. - Page 10 6. Installation and Connecting Pipe 6. Installation and Connecting Pipe Precautions before installation (3) Cooling in the recirculating air mode The room air is extracted from the storage room or a wine cellar, subsequently cooled and dehumidified in the heat pump and finally re-introduced into the room. Recreation rooms, Handle the unit in a proper way；...
-
Page 11: Wire Connection
6. Installation and Connecting Pipe 6. Installation and Connecting Pipe 6. Wire connection Attention Appliances should be installed in accordance with national wiring rules. The lower part of the unit is equipped with the power plug line for connected to the After installing the connecting pipe according to the diagram, open the water tap and the hot power unit. -
Page 12: Operation And Usage
7. Operation and Usage 7. Operation and Usage . Function of wire Function of icons 2） controller Symbol Meaning Funtion The main display area It is showed when unit is turned off. Ventilation It is showed when unit is in ventilation mode. Economic It is showed when unit is in economic heating mode. - Page 13 7. Operation and Usage 7. Operation and Usage The controller usage Starting up and shutting down. ” Press“ ” for 0.5s to start up the unit，and the symbol “ ” In the standby interface, press“ ”for 0.5s to shut down the unit, and the symbol will be off.In the running interface, press“...
- Page 14 7. Operation and Usage 7. Operation and Usage Hours flashing Long press ”twice Press“ “ ” ” Press“ Display 10s ” Minute flashing or“ ” Press“ ” Press“ Clock setting ” or“ Date flashing ” twice，Hours start to flashing ，and press“ In the main interface，press“...
- Page 15 7. Operation and Usage 7. Operation and Usage Timer setting 1) The timer on/off setting operation at heating/ economic/ high requirements/ automatic mode ”hold on until the "tick" is heard "on" and "zone1" is In the main interface，press“ flashing（means the unit timer is on） ，press“ ”again and hold on until the "tick"is ”...
- Page 16 7. Operation and Usage 7. Operation and Usage 2.9 The operation of Fan setting At main interface，you can start up Fan by pressing“ ”for 2s，and thenpress “ ” ” Long press“ for 2s can shut it down. ” Press“ ” Long press“...
- Page 17 7. Operation and Usage 7. Operation and Usage Set-point of target temp. 55°C Ajustable...
-
Page 18: Maintenance And Repair
8.Maintenance and repair 8.Maintenance and repair 1. Maintenance. 2. PCB I/O port It should keep dry, clean and well-ventilated around the units to maintain its good effect OUT1 OUT2 CN19 of heat transfer and energy saving. Check the parts of the unit and the pressure of the system regularly (once 1 year). If AI06 OUT3 there is any unusual phenomena, repair and replace it immediately. -
Page 19: The Normal Failure And Solutions
8.Maintenance and repair 8.Maintenance and repair 4. FAQ The normal failure and solutions Why the compressor is not running when I start up the unit? 1） For any malfunctions, please refer to the table below : Answer：When the unit is powered on after the last shut-down, the compressor will not run Display until 3 minutes later. -
Page 20: Caution & Warning
8.Maintenance and repair 5. Caution & Warning 1. The unit can only be repaired by qualified installer centre personnel or an authorised dealer.（for Europe market） 2. This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
