- Page 1 BOUNCE TABLE TENNIS TABLE & ACCESSORIES ASSEMBLY INSTRUCTIONS NG2325...
- Page 2 THANK YOU! Thank you for your purchase of our product. We work around the clock and around the globe to ensure that our products maintain the highest possible quality. However, in the rare instance that your product is defective or missing parts, contact Challenger Manufacturing at 800-759-0977 to submit parts requests or warranty claims.
- Page 3 PARTS IDENTIFIER (NOT TO SCALE) IMPORTANT! CAREFULLY OPEN AND RETAIN THE CARDBOARD SHIPPING CARTON. IT WILL BE USED TO PROTECT THE PLAYING SURFACE DURING ASSEMBLY.
-
Page 4: Assembly Tips
ASSEMBLY TIPS 1. Find a clean, level surface to begin the assembly of your game table. The table will be par- tially assembled upside down and then turned over onto its legs. This is a heavy table and turning it over will require at least two strong adults. 2. - Page 5 ASSEMBLY INSTRUCTIONS Please note: All bolt and screws should be loosely installed during assembly to allow for move- ment or adjustment of the parts; The bolts and screws should be fully tightened at the end of as- sembly, before turning the table over. 1.
- Page 6 ASSEMBLY INSTRUCTIONS (CONT.) 3. Connect the SIDE PLATES with each CENTER SUPPORT BRACE #4 using BOLT SET C #11. 4. Attach each LEG SUPPORT BRACE #3 with BOLT SET A #9.
- Page 7 ASSEMBLY INSTRUCTIONS (CONT.) 5. Align two LEG BRACKETS #7 with the pre-drilled holes in each TABLE TOP and attach with SCREW #8. Note: The notched sides of the LEG BRACKETS should face the center line of the table. 6. Attach one WHEEL #6 to each of the center legs, pushing down to lock them into place. Tighten all bolts and screws.
- Page 8 ASSEMBLY INSTRUCTIONS (CONT.) 7. Carefully turn the table over. Clip one NET POST #12 to each side of the table at the center line. Attach the TABLE TENNIS NET #13 to each POST. Note: A small gap between the table...
-
Page 9: Care And Use
CONGRATULATIONS! You have now assembled your Game Table. Please note the Care and Use instructions below to ensure years of trouble free use of your game table. CARE AND USE 1. This product is intended for INDOOR use only. 2. Do NOT sit, climb or lean on the table. 3. -
Page 10: Year Limited Warranty
1-YEAR LIMITED WARRANTY This product is warranted to the original purchaser to be free from defects Challenger Manufacturing in material or work manship for a period of ninety days from the date of the original retail purchase. This warranty does not cover defects or damage due to improper installation, alteration, accident or any other event beyond the control of the manufacturer.
