- Page 1 HARVIL YOUTH PORTABLE BASKETBALL HOOP ASSEMBLY INSTRUCTIONS NGD2204...
- Page 2 CONTACT INFORMATION We work around the clock and around the globe to ensure that Harvil products maintain the highest possible quality. However, in the rare instance that your product is defective or missing parts, PLEASE DO NOT RETURN IT TO THE STORE.
- Page 3 PARTS IDENTIFIER (NOT TO SCALE)
- Page 4 ASSEMBLY TIPS 1. Find a clean, level surface to begin the assembly of your basketball hoop. Assembly will require two strong adults. 2. Remove all of the contents from box and verify that you have all of the parts shown on the Parts Identifier before you begin assembly.
- Page 5 ASSEMBLY INSTRUCTIONS 1. Insert one WHEEL SHAFT #17 through each WHEEL #16. Snap each assembled WHEEL into place on the bottom of BASE #7. Note: WHEELS may be pre-installed at the factory. 2. Attach BOTTOM POLE #8 to BASE #7 with WING BOLT #15 through the bottom of the BASE.
- Page 6 ASSEMBLY INSTRUCTIONS (CONT.)
- Page 7 CONGRATULATIONS! You have now assembled your Harvil Basketball Hoop. Please note the Care and Use instructions below to ensure years of trouble free use of your hoop. CARE AND USE 1. Do NOT hang on the hoop rim. 2. Make sure the surface beneath the base is free of stones, gravel or sharp objects that could puncture the base.
