Summary of Contents for Accelleran E1000 Series
- Page 1 E1000 Series LTE Base Station Safety and Installation Instructions © 2018 Accelleran N.V. all rights reserved. Accelleran and the Accelleran logo are trademarks of Accelleran N.V. All other trademarks are the property of their respective owners.
-
Page 2: Table Of Contents
E1000 Series Safety and Installation Instructions Table of Contents Introduction ......................3 Intended Use ....................... 4 Safety ......................... 4 General ......................4 Federal Communication Commission Interference Statement ......5 Professional installation instruction ..............6 Power Supply ...................... 7 Radio Spectrum ....................7 Technical Specification .................. -
Page 3: Introduction
LTE band 48. In the rest of this document, the name E10xx is used to mean any model in the E1000 series. The remainder of this document applies to all E1000 series models, except that in the Technical Description section there is a sub-section for each individual model giving its frequency bands and maximum transmit power. -
Page 4: Intended Use
E1000 Series Safety and Installation Instructions Intended Use The product is intended for use as a base station (eNodeB) in an LTE network. It is designed to be installed outdoors but may also be installed indoors. It is not to be sold to, installed by or operated by the general public. -
Page 5: Federal Communication Commission Interference Statement
E1000 Series Safety and Installation Instructions Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 6: Professional Installation Instruction
RF exposure requirement. 3. External antenna Use only the antennas which have been approved by Gemtek, Accelleran. The non-approved antenna(s) may produce unwanted spurious or excessive RF transmitting power which may lead to the violation of FCC limit and is prohibited. -
Page 7: Power Supply
E1000 Series Safety and Installation Instructions Power Supply The product must be powered using a PoE+ injector conforming to the Type 2 PSE defined in IEEE 802.3at, such as that supplied with the product. The PoE+ injector must be connected to the product using Cat 5e or better cabling. -
Page 8: Technical Specification
E1000 Series Safety and Installation Instructions Technical Specification All E1000 Series Models The Accelleran E10xx is an outdoor, LTE, single cell, single carrier, base station (eNodeB) with the following main features: • 3GPP Local Area Base Station class • LTE radio conforms to 3GPP Release 11 specification •... -
Page 9: Technical Description
E1000 Series Safety and Installation Instructions Technical Description End to End Connectivity The overall end to end connectivity is shown in Figure 2. The EPC, OAM, optional SAS, gateways and backhaul may be supplied by the customer – details vary according to customer requirements. -
Page 10: Mounting Points
E1000 Series Safety and Installation Instructions connectors. Depending on the antenna type chosen, the LTE antennas can be screwed directly onto the connectors (via a Type N male to N male connector if the antenna has a Type N female connector) or can be connected via coaxial cable fitted with a Type N male connector. -
Page 11: Lightning Protection Earthing Point
E1000 Series Safety and Installation Instructions Lightning protection earthing point The lightning protection earthing point is located on the back of the E10xx as shown in Figure 6. Figure 6 - Lightning protection earthing point LTE Antennas LTE antennas are not included with the E1010 or E1011 products. Customers may use any omni-directional antenna that meets the following specification: •... - Page 12 E1000 Series Safety and Installation Instructions • Mains cable for PoE+ injector • Ethernet cable (1.5 m) for connecting the PoE+ injector to the backhaul equipment • IP67 seal for RJ45 connector, with manufacturer’s instructions Figure 7 - Supplied accessories Note: The precise make and model of GNSS antenna and PoE+ injector, and the type of mains plug supplied may vary from those shown in Figure 7.
-
Page 13: Installation
E1000 Series Safety and Installation Instructions Installation The E10xx is designed to be installed outdoors but may also be installed indoors. A pole mounting kit is supplied. If the E10xx is to be fixed to an interior wall, an off the shelf VESA MIS-D 100 mounting bracket or similar may be used (not supplied). -
Page 14: Grounding The E10Xx
E1000 Series Safety and Installation Instructions The E10xx with the mounting kit attached is shown in Figure 10. Figure 10: E10xx with mounting kit Grounding the E10xx Once the E10xx has been installed in its final position, it must be properly... - Page 15 E1000 Series Safety and Installation Instructions 1. Connect a ground lug (not supplied) to one end of the grounding conductor (not supplied) as shown in Figure 11. 2. Remove the grounding screw of the E10xx (see Figure 11). Insert the screw through the grounding lug and screw it back firmly into the E10xx.
-
Page 16: Install The Lte Antennas
E1000 Series Safety and Installation Instructions Install the LTE antennas Antennas that are equipped with a Type N male connector may be fitted directly to the connectors on the E10xx. Alternatively, antennas may be mounted separately from the E10xx using their own mounting kit and connected to the E10xx using coaxial cables terminated in Type N male connectors. -
Page 17: Seal The Rf Connectors
E1000 Series Safety and Installation Instructions Seal the RF connectors If installed outdoors, the LTE and GNSS antenna connectors must be sealed using 3M (or similar) vinyl electrical tape and butyl mastic tape (not supplied) to prevent moisture ingress. Connect the backhaul and power The E10xx is supplied with a suitable PoE+ injector, as shown in Figure 14. -
Page 18: Check Led Indicators
E1000 Series Safety and Installation Instructions 5. Fit the sealing RJ45 connector to the free end of the second Ethernet cable and connect it to the RJ45 socket on the E10xx as per the sealing connector manufacturer’s instructions. 6. Secure the Ethernet cables as necessary so that they do not hang loose. - Page 19 E1000 Series Safety and Installation Instructions connected properly to the equipment that provides the E10xx with its backhaul connection. Sync indicator Following power up, the Sync indicator remains off until the integrated GNSS function is activated. Once the GNSS function has been activated, the Sync indicator blinks slowly until enough satellites have been acquired for a timing lock.
