Additional Features On Your Compactalite Pro Integra 325; Care And Maintenance - Outdoor Revolution Compactalite Pro Integra 325 Instructions

3.
First attach the bracket pads inside the awning in the centre using the short piece of profile located up near the main
awning profile. Next take one of the steel roof pole sections and slide through either of the outer roof channels, then
locate one of the steel vertical poles into position using the ferrel at the end of the fibreglass pole. After this has been
done locate the steel pole into position using the pin on the 'ring and pin' assembly located on the black webbing
around the foot of the awning and then tension the pole by using the fitted adjuster. Next push 1 of the centre poles
through the vent and attach inside the awning by placing the hook into the bracket pad attached earlier and affix the
front leg in the same way as the 1
same way as pole 1. Finally clip the black plastic locating clips on to the steel the poles.
4.
You will now notice the two outer poles will drop inwards onto the awning canvas, in order to rectify this take the
stability strap on one end and peg out, this will pull the pole outwards and hold it in position whilst you work on setting
the awning, after you have done this repeat the process at the other end (only knock the peg in halfway as it is likely
you will have to reset this at the end.) After this has been done the back of the awning by the caravan should now be
pegged through the steel rings at the corners and the buckles tensioned slightly.
5.
The sections for the steel stabiliser pole should now be taken inside the awning. The shaped cross pole should be
opened out and the 2 legs should be attached. If you look at the front of the awning you will see a number of 'zipped
sleeves' and tapes these are to hold the stabiliser pole in place. Unzip the sleeves and offer up the assembly into
position and complete by zipping the sleeves and tying the tapes Then connect the pole legs at either side by using
the metal pins on 'ring and pin' assembly at the base of the awning, then finally zip up the sleeves.
6.
You may notice the front section of the awning may rise up of the ground this is not a problem and once you have the
corners pegged should pull back down (this is due to the tension on the steel stability bar)
7.
Now continue by placing pegs in the 2 front corners of the awning followed by pegging the remaining points along the
front, ensuring all pegging is in a straight line. Remember when pegging to use the 'ring and pin' assemblies as
pegging points through the centre of the ring. (Do not over tension as this can sometimes lead to damaged zips) TIP
pegs perform best when inserted at 45 degrees into the ground.
8.
Peg the gusseted flanges at the rear of the awning in such a way that a seal is formed against the caravan side. The
shock chord can be gently tightened to maximise this seal by pulling tight through the black toggle.
9.
Guy lines can now be tensioned and pegged (remember you may have to re-adjust the yellow stability straps you
positioned earlier) please ensure in heavy weather that ALL guy lines and the stability straps are used.
10.
Take care not to over tension as this can damage your awning or awning zips. (Please note that failure to use all the
lines may result in your awning being damaged)

ADDITIONAL FEATURES ON YOUR COMPACTALITE PRO INTEGRA 325

1) TAGS HANGING FROM THE ROOF ARE TO ATTATCH AN INNER TENT (ADDITIONAL COST
ITEM).
2) THE POCKETS AT THE BASE OF THE DOORS ARE TO ACCOMMODATE THE (FOLDED)
DOOR PANEL IF YOU WISH TO HAVE THE DOOR OPEN.
3) ABILITY TO FIT ANNEXE EITHER SIDE (EXTRA COST OPTION)
4) 300D DOUBLE RIPSTOP WALLS
5) 150D RIPSTOP ROOF
** IN EXTREME WEATHER, TAKE YOUR AWNING DOWN**
Please note these few points for trouble free camping.
a. After use please take extreme care when packing away. Ensure the Compactalite Pro Integra 325 is
dry (including the poles) and air the tent before packing away.
b. Any dirt or stains can be removed by brushing or gently washing with warm water. DO NOT use
detergents as this will destroy the waterproofing on the fabrics.
c. We advise that you DO NOT cook or smoke in this awning; although the outer fabric is fire retardant
treated it will still melt.
d. During use, particularly during rain, avoid touching the outer fabric as this may cause moisture to be
drawn into the porch awning.
e. Please make sure that you have a good time.
**We highly recommend that you insure your awning against storm damage or accidental damage, as the
warranty does not cover such eventualities. The manufacturer is not liable for any damage caused to the
caravan because of misuse, incorrect pitching or extreme weather
st
leg next repeat this process on the next pole, then finally fit the remaining pole the
Outdoor Revolution Awnings are distributed by:
Blue Diamond Products Ltd
WWW.Blue-diamond-products.co.uk
**
