WEG CWB Series Quick Start Manual

CWB95...125
B
mm
CWB95...125
in
10005594420.03
www.weg.net CWB95...125
5,87
WEG Automação
-3 -1
NO NC
-4 -2
CLICK
PHILLIPS #2
2
2 X 1...2,5 mm
1,0 Nm
8.8 lb.in 2 X 18...14AWG
-PROIBIDO ACIONAMENTO
MANUAL.
-MANUAL ACTIVATION IS
PROHIBITED.
-ACTIVACIÓN MANUAL ESTÁ
PROHIBIDA.
-HANDBUCH AKTIVIERUNG
IST VERBOTEN
C
C
mm
A B C
in
A B C
110 120 60
CWB95...125
149 144 72
4.33 4.72 2.36
5.68 2.83
WEG IMPORTERS IN THE EUROPEAN UNION
AUSTRIA - WATT DRIVE ANTRIEBSTECHNIK GMBH - Wöllersdorfer Str. 68, 2753 Markt
Piesting, Wiener, Austria; BELGIUM - WEG BENELUX S.A. - Rue de l'Industrie 30/D, 1400
Nivelles, Belgium; FRANCE - WEG FRANCE SAS - 13 Rue du Morellon, 38297 Saint
Quentin Fallavier, France; GERMANY - WEG GERMANY GMBH - Geigerstraße 7, 50169
Industriegebiet Türnich 3, Kerpen, Germany; ITALY - WEG ITALIA S.R.L. - Via Viganò de
Vizzi, 93/95, 20092 Cinisello Balsamo, Milano, Italy; NETHERLANDS - WEG
NETHERLANDS - Hanzepoort 23C, 7575 DB Oldenzaal, Netherlands; PORTUGAL - WEG
EURO-INDUSTRIA ELECTRICA S.A. - R. Eng. Frederico Ulrich 605, 4471-908 Maia,
Portugal; SPAIN - WEG IBERIA INDUSTRIAL S.L. - C/ Tierra de Barros, 5-7, 28823
Coslada, Madrid, Spain; SCANDINAVIA - WEG SCANDINAVIA AB - Box 27, 435 21,
43533 Mölnlycke, Sweden; UNITED KINGDOM - WEG (UK) LTD - Broad Ground Road,
Redditch B988YP, Worcestershire, United Kingdom.
Information valid for WEG Group Importers.
MAX. CONTATOS
MAX. CONTACTS
4
CWB95...125
MAX. CONTACTOS
MAX. ANZAHL KONTAKTE
NO
CLICK
CWB95...125
RCB DIB
VRB
DIZB
-3 -1
NC
-4 -2
1x 2x
mm 2 2,5...70 6 Nm
AWG 14...2/0 53 lb.in
2
2 X 1...2,5 mm
2
1 X 1...4mm
2 X 18...14AWG
1,0 Nm
1 X 18...12AWG 8.8 lb.in
PHILLIPS #2
1,0 Nm
8.8 lb.in
2
2 X 1...2,5 mm
2 X 18...14AWG
2
1 X 1...2,5 mm
1 X 18...14AWG
Allen
4mm
PHILLIPS
#2
