Instruction Sheet
ProBlue
R
P10/15/30 and P50 Operator's Panel Service Kit - P/N 1028327
This instruction sheet describes the procedure for replacing the operator's
panel on a ProBluet model P10/15/30 or P50 adhesive melter.
1.
2.
local power disconnect switch.
3.
Operator's Panel
CAUTION: Before handling electrical components, ground
yourself by touching any bare-metal part of the chassis or
another grounded structure. Failure to properly ground yourself
can cause electrostatic discharge resulting in damage to the
CPU board.
4.
ribbon cables from the CPU board.
WARNING: Risk of personal injury or equipment damage! Refer to
the safety information provided in the melter manual before servicing
the melter. Failure to comply with the safety information provided
can result in personal injury, including death.
WARNING: Risk of electrocution! The control switch does not remove
high-voltage power from the melter. Before opening the electrical
compartment door, ensure that the local power disconnect switch is in
the off position and that it is locked. Failure to properly disconnect power
from the melter can result in personal injury, including death.
Switch the melter off.
Disconnect electrical power to the melter at the
Open the electrical compartment door.
Disconnect the main board and serial port

Required Tools:

6-mm open-end wrench
Phillips-head screwdriver
4-mm hex wrench
5.
Detach the CPU board by removing
the six threaded spacers and lock washers.
CPU Board
J1
6.
board and the control panel.
P/N 1029723B
Issued 02/05
Disconnect the two ribbon cables that join the CPU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1028327 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nordson 1028327

  • Page 1 Instruction Sheet P/N 1029723B ProBlue P10/15/30 and P50 Operator’s Panel Service Kit - P/N 1028327 Issued 02/05 This instruction sheet describes the procedure for replacing the operator’s WARNING: Risk of personal injury or equipment damage! Refer to Required Tools: panel on a ProBluet model P10/15/30 or P50 adhesive melter.
  • Page 2 Detach the electrical enclosure door by removing the four M5 screws and matching washers. Detach the operator’s panel from both hinges by removing the four locknuts. Assemble the new operator’s panel to the hinges, and then re-attach the electrical enclosure door.
