Page 2: Protection From Electric Shock
Manual | Clou³ Multifunction 3in1 LED Display Video + lighting + movement Declaration • The material in the manual is for standard Squareled Clou³ design. Other specific or special system or function depends on the user’s order. • This products is for professional installation and the user should keep clear of danger. •... -
Page 3: Protection From Fire
Manual | Clou³ Multifunction 3in1 LED Display Video + lighting + movement • Use only a source of power that complies with local building and electrical codes and has both overload and ground-fault (earth-fault) protection. • Connect the LED display to power using only the cables supplied by attached with the product. •... - Page 4 Manual | Clou³ Multifunction 3in1 LED Display Video + lighting + movement 1. Squareled Clou³- Module Feature 2. Squareled Clou³- Main Data Power input 110VAC/50~60Hz Power consumption 380W(Max) Head movement X:540°/Y:120° Control model DMX512 Signal/Sound/Auto DMX channel Net weight ≈31kg Dimension 498(L)*498(W)*595(H)mm 3.
- Page 5 Manual | Clou³ Multifunction 3in1 LED Display Video + lighting + movement 4. Squareled Clou³- Connection between Module Please use the DMX512 shielded twisted pair signal line.The signal line connecting distance is 150 meters.When used for long distance signal transmission, signal amplifier should be added to the DMX512. Since each DMX signal can only control 512 channels, each signal can control no more than 8 pcs of Squareled Clou³.
- Page 6 Manual | Clou³ Multifunction 3in 1 LED Display Video + lighting + movement 4.1 Major Function Turn on the machine, press the “MENU” button to enter the menu mode, use the “UP “and “DOWN “buttons to look up the menu. When the preset menu is displayed on the screen, press the “ENTER”...
- Page 7 Manual | Clou³ Multifunction 3in 1 LED Display Video + lighting + movement Class 1 menu Class 2 menu Class 3 menu Class 4 menu Normal Display Invert Inverted English Language Sett Chinese Calibrate Factory Setting Clean Program Pan Invert Tilt Invert Pan Offset -127 ~ 127...
- Page 8 Manual | Clou³ Multifunction 3in 1 LED Display Video + lighting + movement Class 1 menu Class 2 menu Class 3 menu Class 4 menu Auto Test Tilt XY Speed Shutter Dimmer LED1 color macro 000-255 Test Mode LED2 color macro Manual Test LED3 color macro LED4 color macro...
- Page 9 Manual | Clou³ Multifunction 3in 1 LED Display Video + lighting + movement DMX Channels X R o v er D M X C o n t en t F u n c tio n P ro f ig u re X ax is X r otate 5 40 d eg ree s 16 bit X a xis...
- Page 10 Manual | Clou³ Multifunction 3in 1 LED Display Video + lighting + movement X R ove r C ont ent D M X figure Fu nct io n Pr o ru nni ng s ty le S low to fas t m a cr o S pee d ru nni ng s ty le m ac ro C o lo r 1...
- Page 11 Manual | Clou³ Multifunction 3in 1 LED Display Video + lighting + movement X R o v e r C o n t e n t D M X fi g u r e F u n c t io n P r o B lu e 3 W h it e 3...
- Page 12 Manual | Clou³ Multifunction 3in 1 LED Display Video + lighting + movement X R o v e r C o n t e n t D M X fi g u r e F u n c t io n P r o W h it e 8 R e d 9...
- Page 13 Manual | Clou³ Multifunction 3in1 LED Display Video + lighting + movement Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
