AVALL Shelf Kit
AVS/002/SLF
P A R T S I N C L U D E D :
Shelf brackets
1
R E M O V E A V A L L F R O N T P A N E L
Remove fixing screws
1 A
3
R E C O N N E C T A N D F I X A V A L L C O L U M N S
A V S / 0 0 2 / S L F
AVALL Shelf
Lift off front panel
1 B
Retighten column
clamp screws
REFER ALSO TO MAIN
INSTALLATION INSTRUCTIONS
FOR AVALL STAND
Ladder rails x2
2
T E M P O R A R I L Y S E P A R A T E A V A L L C O L U M N S
A N D I N S E R T M O U N T I N G N U T S I N C H A N N E L
M8 hex nut x2
M8 x 12mm screw
M8 hex nut
x4
M6 x 16mm screw
Loosen column
clamp screws
2 x nuts in each
side of column
x4
x4
