- Page 1 LTE CAT M1/NB2 TRACKER For Asset/Vehicle MODEL: GPT46 User Manual <GNSS + GSM/SMS/EGPRS + LTE CAT M1+ LTE NB2> Long Standby Tracking System...
-
Page 2: Table Of Contents
CATLOG Ⅰ. Product Features........4 Ⅱ. Components and Accessories..6 Ⅲ. SIM Card Installation.......7 Ⅳ. Test & Installation......8 Ⅴ. Setting & Inquiry....... 9 Ⅵ. Device Alarm........10 Ⅶ. Trouble shooting......11 Ⅷ. Warranty Rules......14... - Page 3 If some contents and operation steps are inconsistent with those for the actual product, the latter will prevail. With GPT46 Long Standby GPS Tracker, we can monitor your vehicle or asset by GPS satellite positioning system, GPRS/LTE CAT M1/LTE NB2 communication and Internet, remote location of vehicles or asset can be achieved through a powerful service platform.
-
Page 4: Ⅰ. Product Features
Ⅰ. Product Features ■ Support GSM/SMS/EGPRS/ LTE CAT M1/ LTE CAT NB2 (iOT network) ■ GNSS: GPS/Beidou/Glonass/Galileo/Qzss etc ■ GNSS/Wi-Fi/LBS triple positioning way, Real time tracking /upload data regularly ■ Built-in temperature sensor, support temperature alarm ■ Built-in light sensor, detecting opening door/box behavior. - Page 5 Basic Specifications LTE data (400mA); Work Current GPRS data (500mA) Idle(3mA);30uA(power off) GNSS Accuracy <2M @ Open Sky GNSS Band 1575MHz EGPRS Band 850/900/1800/1900MHz B1/B2/B3/B4/B5/B12/B13/ LTE CAT M1 Band B14/B18/B19/B20/B25/B2 6/B27/B28/B66/B85 B1/B2/B3/B4/B5/B12/B13/ LTE CAT NB2 Band B18/B19/B20/B25/B26/B2 7/B28/B66/B71/B85 <3s，<26s，<35s Hot/warm/cold Start 5500mAh;...
-
Page 6: Ⅱ. Components And Accessories
Ⅱ. Components and Accessories ■ Components -Top Front- (Towards sky) -Bottom - ■ Accessories 3M Velcro (default) -
Page 7: Ⅲ. Sim Card Installation
Ⅲ. SIM Card Installation Open the back door case, check if device is OK and accessories are intact Open device cover Insert SIM Card... -
Page 8: Ⅳ. Test & Installation
Note: ●Please power off device before installing or uninstalling SIM card. ●Open SIM’s traffic transmission to send data. ●If the PIN code of SIM card enable, please use your mobile phone to disable the PIN code. ●Please make sure SIM card has sufficient balance. -
Page 9: Ⅴ. Setting & Inquiry
Fast blinking Searching GPS Satellites Slow blinking GPS works normally 4.3 Install Device Close device door, Stick Velcro to bottom of GPT46 and instill it. Ⅴ. Setting & Inquiry 5.1 Web Platform & APP 5.1.1 Web Browser platform Login the service platform to set or track device, ask your dealer for the WWW address 5.1.2 Smart phone application... -
Page 10: Ⅵ. Device Alarm
5.2 SMS You can write a positioning SMS sending to device to inquiry position, device will reply position SMS or map link once it wake up. You also can set administrator number to get remove alarm. The SMS commands please refer to the Operation Commands. -
Page 11: Ⅶ. Trouble Shooting
the Geo-fence. Note: You need to set the conditions of crossing fence, fence types and so on. 6.5 Low Battery Alarm Conditions: When device’s battery power falls below a certain value . Note: Alarm parameters must be set before work in 6.2, 6.3, 6.4, Please refer to the <Operation Commands>... - Page 12 red and blue LED will intermittently and slowly flick. 4）Inquiry parameters of device via commands and check replied parameters. 7.2 Offline status First check if LED indicators are OK, if cannot check them, you can check SIM card following next steps: 1）...
- Page 13 1）If the vehicle is in the place where there is no GPS signal. 2）The upside of device should be installed with face toward the sky. 3）The GSM & LTE CAT M1/NB2 and GPS signal may be weakened if device is installed in the place with electromagnetic wave absorption material(such as metal blocks), special attention should be paid if there is metal thermal insulation layer or heating...
-
Page 14: Ⅷ. Warranty Rules
Ⅷ. Warranty Rules 8.1 Special statement 1）Technology change without notice. 2) If the color and appearance are inconsistent with those for the actual product, the latter will prevail. 3）Warranty card is only valid for devices with the following IMEI. 4）Please take care of the warranty card and show it with the original purchase receipts when enjoying the warranty service. - Page 15 4）IMEI label is torn or Obscure. 5）Warranty certificate and product models do not match or warranty certificate be altered. 6）Damage caused by force majeure.
