B-K lighting ArtiStar Series Quick Start Manual page 2

with
Standard Installation
Fixture Installation
1. Place tree ring fixture
Move fixture to desired height. Tighten
the entire assembly to the tree with
provided stand-offs.
4. Remove top of transformer housing by
removing (4) #8-32 set screws using 5/64" Allen
wrench.
Transformer housing will be marked for
primary.
7. Replace top of transformer housing with (4)
#8-32 screws with 5/64" Allen wrench.
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
B-K LIGHTING
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF B-K LIGHTING, INC. AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING
IT MAY DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF B-K LIGHTING, INC. IS STRICTLY FORBIDDEN.
TECHNOLOGY
TECHNOLOGY
around tree.
2. Secure by hooking end of strap over two (2)
Phillips screws. Secure by tightening two (2)
Phillips screws with Phillips screwdriver.
5. Bring line voltage cable from power line to
main splice box location. Loosen cord grip on
bottom of splice box, feed linevoltage cable
from power line through, then tighten cord grip
to secure.
40429 Brickyard Drive • Madera, CA 93636 • USA
www.bklighting.com • info@bklighting.com
PALM TREE RING INTEGRAL
559.438.5800 • FAX 559.438.5900
ArtiStar™ Series
3. Connect secondary cable then twist to secure
in place.
LINE
Factory
Transformer
Wired
COM
GROUND GROUND IN HOUSING
WIRING DIAGRAM
6. Make watertight connections from primary
branch circuit to transformer with waterproof
wire connectors. (By Others). Fixtures are pre-
wired at factory on the secondary side. See
wiring diagram.
RELEASED REFERENCE NUMBER
6-30-19 INS-2811-00
Fixture
