Advent ASP20BK19 Instruction Manual page 2

Thank you
for purchasing your new product.
We recommend that you spend some time reading this instruction
manual in order that you fully understand all the operational features
it offers. You will also find some hints and tips to help you resolve any
issues.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
Product Overview
Right speaker
Front view Rear view
2
POWER
1 3
OFF
4
VOLUME
1. Power Indicator 3. Earphones Socket
2. On/Off Switch and 4. AUX IN Socket
Volume Control
5. USB Plug
Connection
1. Adjust the volume to minimum first to aviod extreme volume when first
turning on the speakers.
2. Use a 3.5mm to 3.5mm stereo audio cable to connect your PC or other
compatible audio device to the Right Speaker's AUX IN socket.
3. Connect the USB connector to any USB port on your PC.
4. Adjust the volume to your desired level by turning the volume control.
5. Check that your PC volume level is sufficient.
Powering ON/OFF
• To power on, dial the Volume Control to increase volume. The Power
indicator will light up.
• To power off, dial the Volume Control to decrease volume until OFF
position. The Power indicator will turn off.
AUX IN USB 5V
5
R
AUX IN USB 5V
L R
Hints and Tips
Problem Solution
No Sound • Adjust the volume dial, it may not be turned up.
• Check the unit is fully connected.
Sound is • Another device may be interfering with the unit. Move
distorted the device away from the unit.
• Volume is too high. Adjust the volume control.
Specifications
Model ASP20BK19
Output Power 2W x 2
Power Supply
USB
Left: 88.2 x 75.7 x 148 mm
Dimension (L x W x H)
Right: 103 x 75.7 x 148 mm
581 g
Net Weight
Features and specifications are subject to change without prior notice.
