- Page 1 Quick Start Guide using CONNECT control unit Visit the Members Area on www.wessafety.com for ‘How To’ videos V2.0 09-2019...
- Page 2 Introduction This guide is designed to get your WES system up and running as soon as possible. A full manual can be obtained by signing up to the Members Area of www. wessafety.com. Further contact information can be found on the back page. Setting up your WES System Installing WES...
- Page 3 a call point and the site wide alarm being raised. • The default setting is 00 minutes (i.e. no delay), but can be set in 1 minute increments up to a maximum 10 minutes. • A confirmation screen will be displayed to validate the settings. The Inspection Delay can only be set during the initial activation process.
- Page 4 • Check the settings displayed on screen are the desired settings, and if not, repeat the Initial Setup process before proceeding. The display is shown for the CONNECT below. CONNECT Home Screen (below) 2. Activate Units DO NOT OPEN ANY UNIT AS THIS WILL INVALIDATE THE WARRANTY.
- Page 5 succession. All three LEDs will briefly illuminate and then the amber LED will flash. • This operation activates the unit – no radio connection is established at this point. 3. Unit Numbering with CONNECT • Activated Call Points, Sensors, and other WES units can be added to create a network using the Unit Numbering process.
-
Page 6: Position Units
• After successfully numbering a unit, change the number displayed on the CONNECT unit and repeat the process above for all required units. Note that the Polling feature of WES can perform an automatic integrity test of the first 128 units added to a network. - Page 7 • Sensor units are ceiling mounted and intended for indoor use only. Ensure a risk assessment has been carried out and all reasonable safety precautions are in place before commencing work. • Call Points must be securely fixed, with the antenna upright, to a robust vertical surface such as a wall or trolley.
- Page 8 allowing full physical test of each unit, without activating the site-wide alarm. Call Points can be triggered manually, and Sensors can be triggered using standard test equipment such as smoke spray or heat probe. • Once the System Test is complete, return to the CONNECT unit and press either button to complete the test and exit System Test mode.
- Page 9 Ramtech radio Unit number module Interface Insert model 2AHNO2-RD0-9X Ramtech radio number module CONNECT Insert model 2AHNOW2C- Ramtech MK2 radio number TRLMK2 module XPY1EIQ24NN Ublox R202-02B-02 4G modem All other WES Insert model 2AHNOW2C- Ramtech MK2 radio models contain: number...
- Page 10 Insert model 21246-W2C- Ramtech MK2 radio number TRLMK2 module 8595A-1EIQ24NN Ublox R202-02B-02 4G modem All other WES3 Insert model 21246-W2C- Ramtech MK2 radio models contain: number TRLMK2 module Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada.
- Page 11 This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: This device may not cause interference, and This device must accept any interference, including interference that may cause undesired operation of the device. Conformément à...
- Page 12 For more information, refer to the full WES User Guide and Operation Manual. To access, visit the Members Area on www.wessafety.com Tel: +1 (646) 933-1307 / +44 (0)115 822 3424 Email: info@wessafety.com Web: www.wessafety.com V2.0 09-2019...
