- Page 1 U N I P I L O T P R O ® E L E C T R I C S T E E R I N G D E V I C E I n s tallation M a nu a l...
- Page 2 Copyrights © 2016 TeeJet Technologies. All rights reserved. No part of this document or the computer programs described in it may be reproduced, copied, photocopied, translated, or reduced in any form or by any means, electronic or machine readable, recording or otherwise, without prior written consent from TeeJet Technologies.
-
Page 3: Table Of Contents
UniPilot ® Table of Contents IMPORTANT INFORMATION Introduction........................................ii Legal Disclaimer ......................................ii Safety Information ......................................ii Safety Instructions ................................... ii Warning Alerts..................................iii Caution Alerts ..................................iv INSTALLATION REQUIREMENTS Standard Tool Requirements ..................................iv Vehicle Requirements ....................................iv Vehicle Inspection ......................................iv CHAPTER 1 - COMPONENTS Supported Models ......................................1 UniPilot Pro Main Hardware Kit ................................1... -
Page 4: Important Information
Legal Disclaimer NOTE: Read and follow ALL instructions in this manual carefully before installing or operating the UniPilot Pro system. NOTE: Take careful note of the safety information in the Safety Information section of this manual and the additional safety messages provided throughout this manual and any other supplemental material provided. -
Page 5: Warning Alerts
• The steering system is not designed to replace the vehicle’s operator. NOTE: After the installation of the UniPilot Pro system, verify that all the screws, bolts, nuts, and cable connections are tight. Verify that all the cables have been secured to prevent them from being damaged. -
Page 6: Caution Alerts
• Check for loose or worn steering components. when driving in a straight line. If any part of the vehicle is not in working order, have the system serviced by a qualified technician prior to beginning the UniPilot Pro installation procedure. -
Page 7: Chapter 1 - Components
98-05342 UniPilot Pro Installation Guide The sub-kits that are required for the installation of the UniPilot Pro system are provided in this section. Use this section to verify that all the sub-kits and parts required for the installation are available. -
Page 8: Unipilot Pro Switch Kit
NOTE: All part numbers provided in this manual are subject to change without notice. They are provided as a reference at the time of this writing. Always verify that the part numbers are still valid from your UniPilot Pro dealer if spare parts need to be ordered. -
Page 9: Chapter 2 - Unipilot Pro Installation
® CHAPTER 2 – UNIPILOT PRO INSTALLATION The UniPilot Pro installation process is described below. A detailed process for each step is described in the following sections. 1. Install the Main Gear on the steering wheel 2. Attach the Anti-rotation Pin 3. -
Page 10: Examine Steering Column And Steering Wheel
3 screws touch the three spokes evenly. Figure 9 shows the main gear rotated counter-clockwise until three of the mounting screws touch the steering wheel spokes evenly. This procedure will help to automatically center the gear under the steering wheel. www.teejet.com... -
Page 11: Attach The Anti-Rotation Pin
UniPilot ® Figure 9: Centering Ring Gear The red circles indicate which screws are touching the spokes 4. Check the installation by rotating the steering wheel and Figure 10: Installing Plastic Cover watching for off-center movement of the main gear. Repeat the centering process as necessary. -
Page 12: Install The Esd
ESD to the V-rollers. Figure 14: Roller Engagement Rollers Release Latch Gear Face 3. Ensure that the main gear race has properly engaged the three rollers before closing latch. 4. Rotate the ESD manually to ensure smooth rolling operation. www.teejet.com... -
Page 13: Chapter 3 - Unipilot Pro Anti-Rotation Bracket Installation
CHAPTER 3 – UNIPILOT PRO ANTI-ROTATION BRACKET INSTALLATION The UniPilot Pro anti-rotation bracket is available through your dealer. It should be used for vehicles that are not supported with a custom vehicle-specific bracket. Consult your UniPilot Pro dealer for a list of all available anti-rotation brackets. An Anti-rotation bracket is required to complete the UniPilot Pro installation. -
Page 14: Unipilot Pro Anti-Rotation Bracket Installation Procedure
3. Place the flange bearing assembly over anti-rotation pin. NOTE: It is important that the anti-rotation pin is placed through the flange bearing before attaching the Fifth Wheel Bracket Figure 17: Anti-rotation Pin Engagement Anti-rotation Pin 7. The bracket installation is complete. www.teejet.com... -
Page 15: Chapter 4 - Unipilot Pro Harness Installation
CHAPTER 4 – UNIPILOT PRO HARNESS INSTALLATION Safety Notes NOTE: The vehicle must be powered off during the installation of UniPilot Pro harness NOTE: To prevent the system from any unexpected shut down while operating, check the cable insulation and cable connections to the other instruments. -
Page 16: Unipilot Pro Harness Installation Procedure
FieldPilot Pro & UniPilot Pro documentation for further information. 1. Connect the ESD to UniPilot Pro Harness 30 pin connector to the SCM Pro and tighten the connector screw using a 1/4" nut driver. Tighten to 15 to 20 in-lbs (1.7 to 2.2 Nm). Use only the recommended nut driver and do not over tighten. -
Page 17: Chapter 5 - On/Off Switch
The ESD is equipped with an On/Off switch. This allows the operator to disable the ESD unit without powering down the complete UniPilot Pro system. Position the switch to the ○ [circle] to disable the ESD. Figure 23: On/Off Switch... -
Page 18: Chapter 6 - Care And Maintenance
250 hours of operation or every six months, whichever occurs first, and tighten as necessary. Do not operate the UniPilot Pro system if the SCM Pro is not well secured. A detached SCM Pro may cause sudden loss of vehicle control while in AutoSteer mode. - Page 20 P R O ® E L E C T R I C S T E E R I N G D E V I C E I nstallat ion M a nua l www.teejet.com 98-05342-EN-A4 R1 English © TeeJet Technologies 2016...
