Early Childhood Resources ELR-0638 Manual

Model#: ELR-0638
Mount Laurel,NJ 08054 USA
www.ecr4kids.com
B
A1
C
A2
D
BEFORE ASSEMBLING, MAKE SURE
THERE ARE NO MISSING PARTS.
TIP!
DO NOT FULLY TIGHTEN SCREWS UNTIL ALL
SCREWS HAVE BEEN LOOSELY POSITIONED.
!
A1
Left Side Panel
- Adult Assembly Required. Two
A2
Right Side Panel
adults recommended.
B
Back Panel
- Contains small parts, sharp points
C
Divider Section
and edges.
D
Kick Plate
E
- Do not stand, sit, kneel, climb, lean
Hex Head Screw(10)
or pull on unit for support.
F
- Never leave children unattended.
Hex Key Tool
- Do not place unit near high heat or
G
moisture.
Phillips Head Screw(4)
- Adult Supervision Recommended.
If you experience any difficulties
with this product, please contact us
toll free at 1-888-227-9028
NOTE:
(Monday through Friday,
A Phillips Head Screwdriver 9:00am to 5:00pm Eastern Time).
may be used for
Please do not return to place
assembly (not included)
of purchase as Early Childhood
Resources will replace defective
1
A1
B
A2
1. Attach Right Side Panel(A2) to Back Panel(B) using 3 Hex Head
Screws(E). Tighten with Hex Key Tool(F).
2
WARNING:
2A. On a carpet or protected surface, carefully lay Right Side
Panel(A2) face down as shown.
2B. Position the assembled Divider Section(C) and Kick Plate(D) so the
pre-installed wooden dowels in the sides enter holes in the Right Side
parts and/or product.
Panel(A2) as shown.
Attach Right Side Panel to
Back Panel
X3
E
B
A2
Attach the Divider Section to
the Right Side Panel
B B
D D
C
A2 A2
3
Attach Left Side Panel
A1
D
C
A2
3. Attach Left Side Panel(A1) to the assembled unit, be sure all
the pre-installed wooden dowels in left side enter holes in Left
Side Panel (A1).Using 5 Hex Head Screws(E), and tighten with
Hex Key Tool(F).
4
Attach Kick Plate to Dividers
A1
D
C
A2
4. Attach Kick Plate(D) to Divider Section(C) using 4 Phillips
Head Screws(G). Tighten with Phillips Head Screwdriver.
Version: ELR-0638_AI.D.2010.01.03
X5
E
B
X4
G
