INSTALLATION GUIDE
RADAR MOUNT KIT PXIII - BPEPKITRAD3 (42803000029)
Suits: FORD RANGER 2018+ (PXIII)
3
4
1
ITEM
PART NAME
1
PX3 RADAR MOUNT PLATE
2
M6 X 1.0 NYLOC NUT
3
M6 X 1.0 X 20MM HEX HEAD BOLT
4
M6 X Ø12.5MM FLAT WASHER
http://www.bocar.com.au/products/Bullbars/BPEPKITRAD3
2
5
QTY
PART NO.
ITEM
1
BOCB0029
3
3
6
INSTALLATION
GUIDE
6
7
PART NAME
5
M8 X 1.25 X 30MM HEX BOLT
6
M8 X Ø19 MM FLAT WASHER
7
M8 X 1.25 NYLOC NUT
QTY
PART NO.
2
4
2
Advertisement
Table of Contents
Related Manuals for Bocar BPEPKITRAD3
Summary of Contents for Bocar BPEPKITRAD3
- Page 1 INSTALLATION GUIDE INSTALLATION GUIDE RADAR MOUNT KIT PXIII - BPEPKITRAD3 (42803000029) Suits: FORD RANGER 2018+ (PXIII) ITEM PART NAME PART NO. ITEM PART NAME PART NO. M8 X 1.25 X 30MM HEX BOLT PX3 RADAR MOUNT PLATE BOCB0029 M8 X Ø19 MM FLAT WASHER M6 X 1.0 NYLOC NUT...
- Page 2 Important Notes: • Please read through these instructions from start to finish before commencing any work. • Ensure All bolts are tightened to relevant tension setting listed as below. Bolt tensions Dia. (mm) All bolt tensions are as follows unless otherwise specified. 4/1/2020 Page 2 of 4...
- Page 3 1. Before fitting, please check the chassis mount application is compatible with your vehicle 2. Position the chassis mount on the vehicle chassis rail ends as shown. 3. Fit radar mount plate to the front face of the chassis mount at slot holes, then loosely se- cure it with using : M8 x 1.25 x 30mm hex bolts (2) •...
- Page 4 5. Once bull bar is aligned with vehicle and bolts tightened, align the radar behind the front face of the bar at rectangular hole, ensuring the radar is central to opening and parallel to the front face as show be- low.
