- Page 1 ENGLISH S M A R T E N G I N E E R E D I N G E R M A N Y P E R F O R M A N C E # R I D E B E Y O N D S I N C E 1 9 9 3 B I K E S RIDE BEYOND...
-
Page 2: Front Fender
M5 x10 mm Screw – DIN 7380 IMPORTANT Always wear personal protective equipment. In case you have any doubt, please contact your local Focus dealer. · Losen the M4 Screw (2.5 mm allen) · Insert the Fender Stay (360 mm) ·... -
Page 3: Rear Fender
M4 x 10 mm Screw - DIN 7380 140219006 Stay Clip - Left 140219007 Stay Clip - Right 199219004 M4 Nut - DIN 439 IMPORTANT Always wear personal protective equipment. In case you have any doubt, please contact your local Focus dealer. RIDE BEYOND... - Page 4 6 /8 7 / 22 · Adjust Bridge width · Place it on the Frame · Inset the Fender Main Stay (370 mm) through the Stay Clip · This operation is required on Left and Right sides · Insert Bridge Hook on the Fender ·...
- Page 5 · This operation is required on Main and Auxiliary Stays · With Fender placed · Insert M5x10 Screw and Washer · Thighten it (3 mm allen) DERBY CYCLE WERKE GMBH Siemensstraße 1-3 49661 Cloppenburg, Germany +49 (4471)966-0 www.focus-bikes.com info@derby-cycle.com 1973K0019028 www.derby-cycle.com KD1973K0019028...
