Built-in Electric Stainless
Steel Oven 80L – EUC-OE80S
User Manual
[Revision 1.0 July 2019]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND
MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in
appearance, assembly, inclusions, specifications, description and packaging.
E&OE
© 2019 Eurochef
Advertisement
Table of Contents
Related Manuals for EUROCHEF EUC-OE80S
Summary of Contents for EUROCHEF EUC-OE80S
- Page 1 Built-in Electric Stainless Steel Oven 80L – EUC-OE80S User Manual [Revision 1.0 July 2019] READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
-
Page 2: Safety
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Safety Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or equipment or property damage if not understood or followed. Safety messages have the following symbols:... - Page 3 Built-in Electric Stainless Steel Oven 80L – EUC-OE80S General Electrical Safety General Electrical Safety General Service Information • Inspect electrical equipment, extension • Electrically grounded equipment must have • The equipment must be serviced or cords, power bars, and electrical fittings for...
- Page 4 Built-in Electric Stainless Steel Oven 80L – EUC-OE80S • After unpacking, please dispose of all elements of packaging in a way that will not cause damage to the environment. All materials used for packaging the appliance are environmentally friendly; they are 100% recyclable and are marked with the appropriate symbol.
-
Page 5: Safety Symbols
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Safety Symbols The product may have safety warning labels attached to it, explained below. Understand the symbols on your product and their meanings. If any stickers become unreadable, unattached etc., replace them. - Page 6 Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Slope / Fall Injury Hazard "Slam Dunk" Warning Carbon-Monoxide Hazard Pull Hazard Do not use the product in Be aware that the product Be aware that using the product Do NOT attempt "slam dunk"...
-
Page 7: Table Of Contents
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Table of Contents Safety ................................. 2 Safety Symbols ................................5 Parts Identification ............................ 8 Installation ..............................9 Installing the Oven ..............................9 Electrical Connection ..............................10 Operation ..............................11 Prior First Use ................................11 Digital Display ................................ -
Page 8: Parts Identification
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Parts Identification Name Temperature control knob Oven function selection knob Oven temperature signal light - red Oven door handle Digital display E&OE © 2019 Eurochef... -
Page 9: Installation
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Installation Installing the Oven • The kitchen should be dry and have effective ventilation according to the existing technical provisions. • Main lead behind the oven must be placed in such manner to avoid touching the back panel of the oven because of the heat it develops during operation. -
Page 10: Electrical Connection
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Electrical Connection WARNING! All electrical work must be carried out by a suitably qualified and authorized electrician. No alterations or wilful changes in the electricity supply should be carried out. • Before attempting the connection, check whether the voltage indicated on the rating plate corresponds to the actual mains voltage. -
Page 11: Operation
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Operation Prior First Use • Remove packaging, clean the interior of the oven. • Take out and wash the oven fittings with warm water and a little washing-up liquid. • Switch on the ventilation in the room or open a window. -
Page 12: Setting The Time
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Setting the Time 1. At power on, “12.00", and flashes. 2. The current time can be set with button 1 and 3, 5 seconds after the time has been set, the new data will be saved. -
Page 13: Semi-Automatic Operation
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S 4. When the set time is up, the alarm signal will be activated and the signal function starts flashing again. 5. Press any button, the signal function and alarm signal will go off. Or the alarm signal will be turned off automatically after 2 minutes. -
Page 14: Automatic Operation
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S There are two methods to achieve this setting: First method: Set the cooking time using buttons 1 and 3. 2. End of cooking time automatically change to 5:00. Second method: 1. Set the end of cooking time using buttons 1 and 3. - Page 15 Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Caution! • Work time = end of cooking time – cooking time For example: If the current time is 2:00; cooking time set to be 3 hours; end of cooking time is set to be 10:00, the work time will be 7:00 (7:00 = 10:00 - 3:00).
-
Page 16: Oven Functions
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S 5. When it goes up to 10:00, the alarm signal is activated. The oven is switched off automatically. Caution! • End of cooking time > current time + cooking time <= 10hours •... - Page 17 Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Fan (Defrost) In this function, only the fan works. You can cool the dish or the oven chamber or defrost food. Circular Heater Fan This function allows the oven to be heated up in a forced way with the thermo fan, which is in the central part of the oven chamber.
-
Page 18: Oven Guide Levels
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Oven Guide Levels Baking pans and accessories (oven grid, baking tray, etc.) may be inserted into the oven in guiding levels. Appropriate levels are indicated in the tables that follow. Always count levels from the bottom upwards! E&OE... -
Page 19: Maintenance
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Maintenance By ensuring proper cleaning and maintenance of your oven, you can have a significant influence on the continuing fault-free operation of your appliance. Before you start cleaning, the oven must be switched off and you should ensure that all knobs are set to the "0"... -
Page 20: Removing The Oven Door
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Removing the Oven Door In order to obtain easier access to the oven chamber for cleaning, it is possible to remove the door. To do this, tilt the safety catch part of the hinge upwards. Close the door lightly, lift and pull it out towards you. In order to fit the door back on to the cooker, do the reverse. -
Page 21: Troubleshooting
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Troubleshooting In the event of an emergency, you should: • Switch off all working units of the oven. • Call the service centre. • Some minor faults can be fixed by referring to the instructions given in the table below. Before calling for customer or service support, check the following points in the table. -
Page 22: Baking With The Oven
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Baking with the Oven Baking pastry Most appropriate position for baking is the application of both upper and lower heater, or the hot air. • The baking parameters given in the table are approximate and can be corrected based on your own experience and cooking preferences. -
Page 23: Baking Table
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Baking Table Temp (°C) Temp (°C) Guide level Guide level Baking time Type of pastry (from down (from down (in min.) upwards) upwards) Sweet pastries Raisin cake 160-170 150-160 55-70 Ring cake... -
Page 24: Roasting With The Oven
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Roasting with the Oven Best results are obtained with the engagement of both upper and lower elements. Best heating mode for each type of roasting pan is indicated by bold print in the Roasting Table. -
Page 25: Roasting Table
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Roasting Table Temp (°C) Temp (°C) Guide level Roasting Weight (in Roasting time Type of meat (from time (in grams) (in min.) bottom up) min.) Beef Beef loin 1000 210-230 200-220 100-120... -
Page 26: Grilling With The Oven
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Grilling with the Oven Grill heater is especially suitable for the preparation of low-fat sausages, meat and fish fillets and steaks, and for browning and crisping the roast skin. Safety • Take extra precautions when grilling. Intensive heat from infrared element makes the oven and the accessories extremely hot. -
Page 27: Grilling Table
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Grilling Table Temp °C) Weight (in Guide level (from Type of meat for grill Grill time (in min.) grams) bottom up) Meat and sausages 2 beefsteaks, rare 14-16 2 beefsteaks, medium 16-20... -
Page 28: Specifications
Built-in Electric Stainless Steel Oven 80L – EUC-OE80S Specifications Type Electric Fascia Width x Height 595 x 595mm Built-in Width x Depth x Height 564 x 560 x 600mm Oven Volume Number of Ovens Single Oven Installation Built-in/Wall Oven Finish Colour... - Page 29 ©2019 Eurochef. All rights reserved. No part of this document, including descriptive content, concepts, ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, scanning or recording, or any information storage and retrieval system,...
