KWIK GOAL WC-240 Assembly Instructions Manual

ASSEMBLY INSTRUCTIONS FOR WC-240 & WC-240AS
1. Unpack all parts and check for damage that may have occurred during shipping. If damage has occurred,
notify trucking company immediately. Lay out all parts. Remove all cardboard and packaging immediately.
Wet or damp packaging may damage contents.
2. Read through entire instruction before beginning assembly and installation.
NOTE: Components may be packaged in one or more additional boxes.
Plastic Cable Tie (4)
(Part# JZ225 Pack of 4)
Net (1)
(Part# WC-24GAW)
Net Fastener (6')
(Part# MNF-1 Roll of 12')
This training equipment has been designed to be used for training only. Training equipment must be anchored AT ALL
TIMES and shall be secured against overturning. Do not climb on the net or frame at any time! All fastenings must be
checked to insure they are fully secured before and after each use of this product. Training equipment not in use must
be disassembled and properly stored in a safe, secure area. Assembled training equipment should not be left
unattended. Do not use this equipment during the threat of high winds. Training equipment should be checked for
safety before and after each use. All warning and safety labels included with this product must be visible at all times.
Any modifications to this or any Kwik Goal product will void any and all warranties.
Crossbar Corner (2)
(Part# UZ1554)
