KWIK GOAL 10B5303 Assembly Instructions

1. Unpack all parts and check for damage that may have occurred during shipping. If damage has occurred,
notify trucking company immediately. Lay out all parts. Remove all cardboard and packaging immediately.
Wet or damp packaging may damage contents.
2. Read through entire instruction before beginning assembly and installation.

Parts

NOTE: Two anchors secures one full size soccer goal in most soils. Each anchor is rated at 500 lbs. when
installed properly.
Auger Piling (2)
(Part# VZ589)
All sports equipment must be anchored at all times. Sports equipment not in use must be
disassembled and stored in a safe, secure place. Assembled sports equipment should not be left
unattended. Do not use this equipment during the threat of high winds. Sports equipment should
be checked for safety on a regular basis. Any modifications to this or any Kwik Goal product will
All Kwik Goal products carry a Lifetime Guarantee. For help with
guarantee issues, visit kwikgoal.com and click on the Lifetime
Guarantee logo or contact customer service at
ASSEMBLY INSTRUCTIONS FOR 10B5303 BOX ANCHOR
Box Anchor (2)
(Part# VZ581)
Cable Lanyard X 6 1/4" (2)
(Part# VZ583)
6- 1/4"
Padlock with Keys (2)
(Part# VZ563)
void any and all warranties.
140 Pacific Drive Quakertown, PA 18951
(P) 215-536-2200 / (P) 800-531-4252 / (F) 215-536-4309 / (F) 800-778-8869
Visit our website @ kwikgoal.com
Hex Driver (1)
(Part# VZ140)
Hardware
3/8" X 1-1/4" Socket Head
3/8" Flat Washer - Steel
3/8" Flat Washer - Polyurethane
***CAUTION***
2011 Kwik Goal Ltd.
.
1-800-531-4252
Cable Lanyard X 36" (2)
(Part# VZ588)
36"
(Part# TZ324)
(Part# TZ189)
(Part# TZ328)
(2)
(2)
(2)
NZ295 Rev. 03/25/11
