- Page 1 Installer Reference Guide Rev 1.20 ® RF120 SMART RF Base Station - RS485 RoHS...
-
Page 2: Mounting Considerations
Case (Front & Back) + LED Light Pipe + Cam Lock Each receiver fitted to the system must be assigned a Instruction Sheet unique address on the LAN. The RF120 includes a DIP Bosch RF Device Compatibility switch for quick address selection. The following table... -
Page 3: Installation
CAUTION - Figure 3 below is a guide only and is not a 1: 1 mounting template for the RF120. Do not scale. Rear Tamper... - Page 4 BLUE = LAN B sent. Where two or more RF120 receivers are required to achieve the desired coverage area there can be overlap- ping areas where multiple receivers detect the same RF device. The system will determine the receiver with the strongest signal level and process it accordingly.
- Page 5 Configuring RF110 Keyfob Button Functions Disabled MENU 6-2-6 is used to customise the button functions Disarm on the RF110 SMART RF 2-way keyfobs. Each of the 5 buttons can be programmed with two independent functions if required with buttons 1 to 5 being a single Part 1 press function and buttons 6 to 10 being hold down Part 2...
- Page 6 Optional RF110FK Fascia Kit An option fascia kit is available to allow customers to personalise their keyfob or to match corporate colours etc. Each kit is supplied with 7 different coloured facias which have been pre installed onto top covers. To change a fascia simply remove the screw from the back of the keyfob, lift off the existing top cover and fascia then replace with the new colour.
- Page 7 Figure 11: RF120 / RF121 Connection Diagram RF120 Specifications Part Number: RF120 - SMART RF Base Station - RS485 Operating Voltage: 10V D.C. - 14V D.C. @ 70mA Max. 12V D.C .nominal Module Connection: RS485 LAN Frequency: 433.42 MHz...
- Page 8 IGIFLE 18 Brumby Street Seven Hills NSW 2147 AUSTRALIA Phone: (+612) 97417000 Email: sales@digiflex.com.au www.digiflex.com.au Our Vision Is Your Peace Of Mind Made in Australia Copyright © 2002-2020 Digiflex Pty Ltd P/N : RF120IRG Rev 1.20...
