Unpacking

2.1

Package Contents

The WebNet Start kit consists of the following items:
How To Get Started sheet (See also apendix A).

The WebNet DIMM module.

The WebRJS adapter board.
An AC adapter (240V/50Hz).
An ethernet UTP Cat. 5 interface cable (2 m).
An RS-232 DB9BU interface cable (1,8 m)
WebNet User's Guide.
2.2 The WebNet DIMM Module
The front side of the WebNet module is the one with the IC with the white label on it. On
Figure 2, the numbers indicate:
1. The ethernet status LED's
2. Battery clip for real-time clock backup battery (from WebNet rev. 4)
WebNet User's Guide
Figure 2: The WebNet DIMM module
