Flex I/O Profibus
Adapter 3170-PDP

Compliance to European Union Directives

If this product has the CE mark it is approved for installation within the European Union and EEA regions. It has been designed
and tested to meet the following directives.
EMC Directive
This product is tested to meet Council Directive 89/336/EEC Electromagnetic Compatibility (EMC) and the following standards, in
whole or in part, documented in a technical construction file:
• EN 50081–2 EMC - Generic Emission Standard, Part 2 - Industrial Environment
• EN 50082–2 EMC - Generic Immunity Standard, Part 2 - Industrial Environment
This product is intended for use in an industrial environment.
3170-PDP Installation Guide
FLEX I/O PROFIBUS Adapter
3170-PDP Profibus DP
Installation Instructions
The following documents are available off the website:
http://www.prosoft-technology.com
User & Programming Manual
3170-PDP GSD File - PSFT0882.GSD
Profibus
Connector
Flexbus
Connector
24V common
connections
24V dc
connections
Node Address
Switches
1
March 1, 2019
Pub# 801.09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3170-PDP Profibus DP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ProSoft Technology 3170-PDP Profibus DP

  • Page 1 FLEX I/O PROFIBUS Adapter 3170-PDP Profibus DP Installation Instructions The following documents are available off the website: http://www.prosoft-technology.com User & Programming Manual 3170-PDP GSD File - PSFT0882.GSD Flex I/O Profibus Adapter 3170-PDP Flexbus Connector 24V common connections LED indicators 24V dc...
  • Page 2 Mounting Instructions 1. Position the PROFIBUS adapter module (A) on a 35 x 7.5mm DIN rail (B) (A-B pt. no. 199-DR1; 46277-3; EN 50022) at a slight angle 2. Hook the lip on the rear of the adapter onto the top of the DIN rail, and rotate the adapter module onto the rail. 3.
  • Page 3 Wiring Profibus Connector Pin # RS-485 Reference Signal Description Not used Not used B/B' RXD/TXD-P Receive/transmit data - P CTNR-P Control signal for repcaters C/C' DGND Data ground Voltage plus (+5V) not used A/A' RXD/TXD-N Receive/transmit data - N CTNR-N not used Metal Shell Earth Ground...
  • Page 4 3170-PDP Specifications Set the Node Address Set the node adress using the2-position pen-push switches. Use a ball-point pen to press either the + or – buttons to change the 3170-PDP Flex I/O Profibus number. Valid settings range from 00 to 99 Adapter Specifications I/O Capacity 8 modules...
  • Page 5 Configuration differences between 1794-APB and 3170-PDP There are two things that must be taken in consideration when replacing the A-B adapter with the ProSoft Technology, Inc 3170- PDP adapter. These items are further described in this document. 1. GSD file The 1794-APB has a Rockwell GSD file with a Rockwell "Profibus Ident Number"...
