PolyGard
DGC- 05
Digital Gas Controller DGC- 05 System
Serial Number _E_1206
Guidelines for Wiring and Commissioning of the Hardware
Service Tool STL
December 2006
PolyGard is a registered trademark of MSR
GAINBDGC05_E_1206
Phone.: 0049(0)8531/9004-0
Fax: 0049(0)8531/9004-54
Specification subject to change without notice
MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking
www.msr-electronic.de
Made in Germany

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PolyGard DGC-05 and is the answer not in the manual?

Questions and answers

Related Manuals for MSR PolyGard DGC-05

Summary of Contents for MSR PolyGard DGC-05

  • Page 1 Guidelines for Wiring and Commissioning of the Hardware Service Tool STL December 2006 PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 2: Table Of Contents

    Configuration card Alarm relay......................26 Configuration card: Measuring points ....................27 PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 3: Preliminary Remark

    = Terminating resistor Fig. 1 Structure line topology PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 4: Application Of Repeaters

    Cable length per segment max. 900 m Fig. 3 Overview: Repeater installation in the field PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 5: Termination

    Fig. 4 Termination at the DT- 05 / GC -05 PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 6: Physical Load Capacity Of The Bus Cable

    L2; L3... (m) 950* *Cable length of max. 900 m exceeded! PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...
  • Page 7 (pieces) (pieces) L feed (m) L return (m) L2; L3...(m) PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 8: Technical Data For The Calculation Of Individual Field Bus Cable Lengths

    Fig. 7 Connection diagram DT- 05 (2- or 3- wire connection) PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 9: Mounting / Electrical Connection

    For the exact position of the terminal s of the alarm relays see the following connection diagram. PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 10: Connection Diagram

    Relays mapped dead-voltage Fig. 8 Connection diagram supply / GC -05 PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...
  • Page 11 Relays mapped diagram dead-voltage EP- 05 modules 1 to 3 PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...
  • Page 12 Fig. 10 Connection diagram EP- 05 modules 4 and 5 PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...
  • Page 13 -Number of DT-05 + AT33XX max.: 24 Fig. 11 Connection diagram: Field bus connection PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...
  • Page 14 Fig. 13 GC- 05 Controller und EP- 05 module PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 15: Commissioning

    Fig. 14 Example: Wiring and connection of a DT- 05 transmitter to an AT-X2-34XX transmitter PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 16: Check Short-Circuit / Interruption / Cable Length Of The Bus Leads

    DGC-05 central control DT-05 DT-05 DT-05 Fig. 15 Loop resistance PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 17: Check Voltage And Bus Polarity Of The Field Bus

    + 24V DT-05 DT-05 DT-05 Fig. 16 Measurement of field bus PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 18: Addressing Dt- 05 Transmitters

    DT- 05. Addressing DT- 05 finished. Unplug service tool. PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 19: Communication Error

    Only line topology <> No branch lines !! Cable length depending on the load. See 3.4 PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 20: Commissioning Of Expansion Modules Ep- 05

    26 to 30 11 to 12 With the DGC- 05 systems by MSR-E, the complete configuration of the EP- 05 modules is already factory-set. Configuration only is necessary with single modules or in case of retrofitting or exchange of a module.

  • Page 21: Calibration

    Page Calibration New transmitters are always delivered factory-calibrated by MSR-E. This is stated by the calibration label indicating date and calibration gas. In this case calibration is not necessary during commissioning. For the calibration of the DT- 05 (MP X.1) an automatic routine is deposited in the menu “Calibration” of the service tool DGC-05-STL.
  • Page 22 Prior to calibration please read also the section “Credit system”. The calibration procedure is described on the next page. PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 23: Calibration Menue

    (The display is adjusted by the potentiometers at the AT-XXX according to the calibration gas. PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 24: Credit System

    New credit points can be loaded by entering a 4-digit code without laborious returning of the STL device to MSR- By stating the 6-digit STL serial number this code can be asked at MSR- E by phone. A block of 100 new credit points is released with each code number.

  • Page 25: Technical Data

    One year on material and workmanship * Data for plastic housing version PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 26: Configuration And Parameter Cards

    R 26 R 27 R 28 R 29 R 30 PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...

  • Page 27: Configuration Card: Measuring Points

    08.1 08.2 09.1 09.2 10.1 10.2 11,1 11.2 12.1 12.2 PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...
  • Page 28 20.1 20.2 21.1 21.2 22.1 22.2 23,1 23.2 24.1 24.2 PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...
  • Page 29 32.1 32.2 33.1 33.2 34.1 34.2 35,1 35.2 36.1 36.2 PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...
  • Page 30 44.1 44.2 45.1 45.2 46.1 46.2 47,1 47.2 48.1 48.2 PolyGard is a registered trademark of MSR GAINBDGC05_E_1206 Phone.: 0049(0)8531/9004-0 Fax: 0049(0)8531/9004-54 Specification subject to change without notice. MSR-Electronic GmbH, Würdinger Str. 27, D 94060 Pocking www.msr-electronic.de Made in Germany...
