Binding; Trim - XciteRC PARACOPTER RTF Manual

Remote control system
1. On / Off Switch: Turns the power of
the transmitter ON / OFF
2. Control lever: direction right or left
3. Control trim: adjusts the straight
fl ight
4. Throttle stick: controls the rise or
sink of the model
5. Throttle trim: adjust the neutral po-
sition of the controller (always in the
middle position!)
6. POWER LED: indicates the battery
voltage
7. Antenna

BINDING:

The 2.4 GHz receiver of PARACOPTER must be once „connected" with a suitable transmitter, the so-called
„binding" procedure. This ensures that the receiver establishes a connection only with this transmitter and the
model can be operated without interference. This process can be repeated any time.
The transmitter and receiver of the PARACOPTER are already bound so that you can start fl ying immediately.
Should a rebind gets necessary (eg. after a transmitter change), proceed as follows:
• Make sure that no other 2.4 GHz network (eg. WLAN or other transmitter) sends nearby.
• The distance between transmitter - PARACOPTER should be maximum one meter.
• Switch transmitter and PARACOPTER on. Now press the button of the receiver unit on the bottom of The
PARACOPTER (Fig.) - the green LED starts to fl ash red. After about 5 seconds it will turn back to green,
the transmitter is now bound to the PARACOPTER.
• If the LED remains red, repeat the steps.

Trim

On both control sticks the neutral position of the servos and speed controller can be precisely adjusted by
pressing on the corresponding side of the rocker trim. Thus, e.g. the straight fl ight can be set precisely.
• Switch transmitter and then the PARACOPTER on.
• Move the throttle stick to the top and then all the way down (see illustration). The motor may not start in
this stick position, but if yes, press the lower part of the left rocker trim until the motor stops.
• Move the control lever to the center position. Watch the red servo arm of the PARACOPTER, it should
now be exactly horizontal. If not, press the right side of the rocker trim to correct it clockwise, the left side
for a counterclockwise rotation. The PARACOPTER now should just fl y straight.
• In fl ight you can correct in the same way as you press the right side of the rocker trim when the PARA-
COPTER pulls to the left, and vice versa.
Throttle lever
Rise / Descent
Trim
Rise / Descent
PARACOPTER
Throttle lever
Rise / Descent
Trim
Rise / Descent
ON/OFF switch
Control lever
Left / Right
Trim
Left / Right
Antenna
Control lever
Left / Right
Trim
Left / Right
