B A N J O T W I N
Thank you for choosing the K&K Banjo Twin! The
Banjo Twin works well in passive mode; if a preamp
should be necessary we recommend our Pure XLR
Preamp.
Before installation please make sure the intonation
(placement of the banjo bridge) is correct. This
manual shows the installation process on a closed
back banjo. If you have an open back banjo some of
the steps shown are not necessary, of course.
1. Remove the resonator and lay your banjo upside
down in front of you.
2. Check the materials included in the package:
•
Banjo Twin pickup
•
8 cable-ties (4 pcs for spare)
•
8 semi-circle shaped, white foam tape mounting
pieces with adhesive and protective paper on
both sides (2 sets, one for spare)
•
4 pieces 9mm wide masking tape gaping strips
(2 sets, one for spare)
92798 Cape Arago Hwy, Coos Bay, OR 97420 | 541-888-3517 | Toll Free 1-800-867-6863 | kksound.com
3. Mark the center of both outside feet of the banjo
bridge.
4. Apply the 9mm wide gaping strips exactly in line
with the bridges feet, starting on the center marks
outward.
Advertisement
Related Manuals for K&K Sound BANJO TWIN
Summary of Contents for K&K Sound BANJO TWIN
- Page 1 B A N J O T W I N Thank you for choosing the K&K Banjo Twin! The 3. Mark the center of both outside feet of the banjo Banjo Twin works well in passive mode; if a preamp bridge. should be necessary we recommend our Pure XLR Preamp.
- Page 2 5. Install the semi-circular foam pieces exactly as 7. Remove the 9mm gaping tape strips. Remove the shown on the photo, beginning from the center protective paper on top of the semi-circular foam marks outward. The gaping tape provides the exact tape pieces.
- Page 3 9. Stick the dual-lock tape that is on the jack into the 11. Secure the pickup cables with 2 cable-ties on the left-of-tailpiece soundhole in the rim. upper rod. This is VERY important as an unsecured cable will make noise that sounds like distortion or similar noise when plugged in.
- Page 4 Stick the single dual-lock piece you removed in step 8, to the banjo's tone ring (or resonator, on a closed back model) and then press the jack's dual-lock tap onto it. We hope you enjoy your Banjo Twin!
