PIKO 56301 Instructions For Use Manual

Diesel loco df7c

Advertisement

Quick Links

一般操作说明
适用于所有DF7C型内燃机车模型
Bedienungsanleitung Diesellok
Instructions for use diesel loco
DF7C型内燃机车
CN
D GB
USA

Advertisement

loading
Need help?

Need help?

Do you have a question about the 56301 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PIKO 56301

  • Page 1 一般操作说明 适用于所有DF7C型内燃机车模型 Bedienungsanleitung Diesellok Instructions for use diesel loco DF7C型内燃机车 D GB...
  • Page 3 Inhaltsverzeichnis: Seite: 内容: 页: Vorbildinformationen 机车简介 Sicherheitshinweise 安全须知 Wichtige Hinweise 重要提示 Belegung der Schnittstellen 接口分配 Table of Contents: Page: Information about the prototype Safety Notes Important Notes Assignment of PluX interface...
  • Page 4 机车简介: 中国在1991年至2001年间共下线交付了289台DF7C型内燃电传动机车用于调车作业与小运转牵引。 该六轴机车因出色的运行性能也被一些工厂及煤矿企业广泛地用作自备机车。 这种具有多种牵引功能的机车因加速快,油耗低,维护方便,在现场作业中很受操作人员的欢迎。 该型机车车钩中心距为18800 mm,总重为135 t,装机功率为1840kW。 该型机车的最高运行速度为100 km/h。 Vorbildinformation: Zwischen 1991 und 2001 wurden in der Volksrepublik China 289 dieselelektrische Lokomotiven der Reihe DF7C für den Rangierdienst und Übergabezüge ausgeliefert. Die sechsachsigen Maschinen zeichnen sich aber auch bei Industrie- und Bergbauunternehmen durch ihre ausgezeichneten Laufeigenschaften aus.
  • Page 5 The prototype: In the People‘s Republic of China, 289 diesel-electric locomotives of the series DF7C were delivered for shunting operation and delivery trains between 1991 and 2001. But the six-axle engines distinguish themselves by their excellent running characteristics also at industry and mining enterprises. Thanks to their high acceleration, the low fuel consumption and the simple maintenance, the locomotives which are suitable for multi-traction enjoyed very quickly a great popularity with the locomotive staffs.
  • Page 6 注意:重要安全指示 正确处理本产品(电子废弃物) (适用于欧盟国家和其他具有独立回收系统的欧洲国家/地区 本产品标签及其文字表明,在本产品使用寿命之后,不得将其与普通生活垃圾一同处理。 请将本设备与其他废物分开处理, 以避免因未经检查的废物处理而对环境或人体健康造成危害。 请您将该设备回收以促进材料资源的可持续再利用。 个人用户请联系购买产品时的经销商或相关机构,以了解怎样以环保的方式回收本设备。 商业用户则应联系供应商并查阅销售合同的条款。 本产品不得与其他商业废物一起处理。模型 - 非玩具! 请保留附入的说明书。 注意!由于要如实的仿照真车的外观设计和功能需要,本产品包含尖锐边角。 使用不当会造成模型或身体损伤。 该模型仅可用带有以下 的已认可的变压器驱动 ; 交流电:最大电压:16V~,转换电压:24V~, 直流电:12V Sicherheitshinweise: Korrekte Entsorgung dieses Produkts (Elektromüll) (Anzuwenden in den Ländern der Europäischen Union und anderen europäischen Ländern mit einem separaten Sammelsystem) Die Kennzeichnung auf dem Produkt bzw.
  • Page 7 Safety Notes: Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of this working life.
  • Page 8 如果经常使用,可以在车轮上加上不含树脂、 非酸性机油! 我们建议,让此 机车模型不断转换方向地行驶大约25分钟, 以便让它保持最优的回转及良好的牵引力。请注意,只有在清洁的轨道上才能保证此模型行驶畅顺。 PIKO Art.-Nr. #56301 比高机油 #56300 机油注油器...
  • Page 9 Rundlauf und eine gute Zugkraft erhält. Bitte beachten Sie, daß der einwandfreie Lauf des Modells nur auf sauberen Schienen gewährleistet ist. PIKO Art.-Nr. #56301 Lok-Öl (50 ml) #56300 Lok-Öler mit Feindosierung If used frequently, oil the wheelsets with a drop of non-resinous, acid-free sewing machine oil! In order to achieve the best possible running and traction properties, it is advisable to run the locomotive in for 25 minutes forwards and 25 minutes in reverse without load.
  • Page 10 Belegung der PluX Schnittstelle PluX接口分配: F0f / F0r - weisse Stirnbeleuchtung v+h F0f / F0r - 白色大头灯,前 + 后 AUX1 - 尾灯 司机操纵台2 AUX1 - Rücklicht Führerstand 2 AUX2 - 尾灯 司机操纵台1 AUX2 - Rücklicht Führerstand 1 AUX3 - Fernlicht, vorne AUX3 - 远光灯,前...
  • Page 11 Assignment of PluX interface F0f / F0r - white headlight front and rear AUX1 - back light driver cab 2 AUX2 - back light driver cab 1 AUX3 - long distance light , front AUX4 - long distance light , rear AUX5 - drivers cab lighting AUX6 - undercarriage lighting AUX7 - shunting light, front + rear...
  • Page 12 Kapazität von mindestens 680 680 nF。 Nanofarad aufweist. 请注意: 如需其他语言版本的安全须知,请您访问: www.piko-shop.de Achtung: Sicherheitshinweise in weiteren Sprachen finden Sie unter: www.piko-shop.de Attention: Safety instructions in other languages, please see: www.piko-shop.de PIKO Spielwaren GmbH Lutherstraße 30 • 96515 Sonneberg • GERMANY 52708-90-7000...
