HomeAgain Universal Worldscan Reader Plus Quick Start Manual page 3

G S
ETTING TARTED
UWSR+ comes supplied with six AAA rechargeable NiMH batteries which
must be fully charged prior to use, as diagram below (step 1 through 3).
If preferred, six standard AAA alkaline
should not be charged (follow only step 1).
Step 1 – Remove retention screw located on bottom back
of UWSR+. Place batteries according to polarity indicators.
Replace lid and screw.
Step 2 – Remove USB plug and attach cable to UWSR+.
Step 3 – Plug the adaptor into power outlet. The battery
level icon will flash while charging and stop flashing when
fully charged. A full charge will take approximately 3 hours.
DO NOT MIX RECHARGEABLE AND STANDARD BATTERIES
DO NOT ATTEMPT TO CHARGE STANDARD ALKALINE BATTERIES.
CHARGE THE BATTERIES INDOORS ONLY AND BETWEEN 0°C AND
40°C.
To extend battery life, charge unit at least every three months, if
reader is unused.
We recommend Duracell
2
or Energizer alkaline batteries
® ®
batteries can also be used and
2
