Summary of Contents for ALGE-Timing Timy3 W

  • Page 1 Version: E200128 Manual General...
  • Page 2 Important Information General Before using your ALGE-TIMING device read the complete manual carefully. It is part of the device and contains important information about installation, safety and its intended use. This manual cannot cover all conceivable applications. For further information or in case of problems that are mentioned not at all or not sufficiently detailed, please contact your ALGE-TIMING representative.
  • Page 3 Rotkreuzstrasse 39 A-6890 Lustenau declare under our sole responsibility, that the timing device Timy3 W-F and Timy3 WP-F complies with the following standards/normative documents and in case of intended use com- plies with the basic requirements of R&TTE 1999/5/EC: Telecommunication (TC)terminal device Short Range Device When used as intended complies with the basic requirements of §3 and the other relevant Provisions of...
  • Page 4 F ..silicon keyboard G ..carrying band eyelet 1 ... USB interface 2 ... charging socket 3 ... ALGE-TIMING multiport 4 ... connection for display board 5 ... connection for start impulse 6 ... connection for finish impulse ALGE-TIMING 7 ...

  • Page 5: Table Of Contents

    Manual Timy3 - General Table of contents Device Description ...................... 7 Timy3 Models ...................... 7 Timy3 Software ....................8 Driver Installation ....................8 Keypad ........................ 9 Display of Timy3 ....................10 Choose Language ..................... 11 Start Up ........................12 Switch On ......................12 Switch Off ......................
  • Page 6 Manual Timy3 - General CHANNELS ...................... 23 9.3.1 INTERNAL ............................. 23 9.3.2 BEEP ............................. 24 9.3.3 TED-RX ............................24 9.3.4 CHANNEL-PATTERN ........................24 9.3.5 WTN Delay ............................ 25 9.3.6 ENABLE DISABLE ........................25 9.3.7 CHANNEL-USAGE ........................25 9.3.8 PULSE HOLD ..........................25 DISPLAY ......................

  • Page 7: Device Description

    Timy3 - General Device Description The ALGE-TIMING Timy3 is a handy device, equipped with high-quality technology. In spite of the handy dimensions, the Timy3 provides a large and easy-to-use silicone keypad. The model Timy3 WP has an integrated printer that records the entire competition.

  • Page 8: Timy3 Software

    CC False Start: false start detection for cross country skiing sprint events 1.3 Driver Installation For installation of drivers, separate manuals are available. You can download them from our or contact your ALGE-TIMING representative. website www.alge-timing.com...

  • Page 9: Keypad

    Manual Timy3 - General 1.4 Keypad The Timy3 has a weather-proof (water-proof) silicone keypad. The keypad is ideal for outdoor use. The keys are raised and have ideal pressure points. Although the Timy3 is small in di- mensions, the keys are easy to operate. Control keys: all-purpose keys;...

  • Page 10: Display Of Timy3

    Manual Timy3 - General 1.5 Display of Timy3 The Timy3 has a display with backlight. The backlight makes reading of the display at bad light conditions easier. As the backlight consumes energy it is only switched on automatically when the Timy3 is connected with an external power supply (e. g. PS12A). If you use the Timy3 in battery mode you can switch on the backlight in the menu.

  • Page 11: Choose Language

    Manual Timy3 - General 1.6 Choose Language Currently, you can choose between the following languages: German, English, French, Italian, Spanish, Finnish and Dutch. • Press menu key. • Select <GENERAL> or <ALLGEMEIN> with arrow down key. • Press OK-key (red or green). •...

  • Page 12: Start Up

    • external battery e. g. 12V plumb rechargeable battery • ALGE-TIMING display board (e. g. GAZ4 or D-LINE) NLG4 and NLG8 must NOT be used as the off-load voltage is too high. The Timy3 might be destroyed! With external supply of at least 11.0 VDC, the internal rechargeable batteries are charged.
  • Page 13 Timy3 - General Internal supply: The battery compartment has space for six batteries type AA or rechargeable batteries. For Timy3 WP you have to use the heat-sealed rechargeable battery-packs ONLY! Timy3 W Timy3 WP Timy3 (Design 2) -20°C / -4F 20°C / 68F...

  • Page 14: Printer

    Printer The Timy3 WP has an integrated thermal printer. We recommend using our ALGE-TIMING pa- per as it is best suited. You can recognize it by the ALGE-TIMING logo print on the reverse side, available with your ALGE-TIMING representative. 3.1 Change of Paper for Timy3 WP (Design 2) •...

  • Page 15: Synchronizing

    Remove the GPS receiver from the Timy3. Press start the selected program. Synchronization of Timy3 from another Timing Device The Timy3 can be synchronized via your start channel C0 from any ALGE-TIMING timing de- vice. You can also synchronize multiple timing devices at the same time. •...

  • Page 16: Synchronization Of Other Devices With Timy3 By Cable

    Manual Timy3 - General • check if all timing devices started • trigger the start again and check if the start time is the same for all devices • disconnect the sync cable if the start times were the same 4.3 Synchronization of other Devices with Timy3 by Cable The Timy3 can send a synchronization signal via channel 0 every full minute when using the programs BACKUP or PC-...

  • Page 17: Synchronization Of Timy3 To Timy3 By Wtn

    Manual Timy3 - General 4.4 Synchronization of Timy3 to Timy3 by WTN It is possible to synchronize the Timy3 from another Timy3 via WTN. For this, the devices must be set to WTN mode and within radio range. There are two ways for synchronization. Adjustment: •...

  • Page 18: Connection Of Auxiliary Devices

    Manual Timy3 - General Connection of Auxiliary Devices A wide range of devices can be operated with the Timy3. Please ask your ALGE-TIMING repre- sentative for the possibilities. 5.1 Channels The Timy3 has nine independent timing channels. Attention: Channels 0 to 5 have a maximum precision of 1/10,000 seconds but channel 6 to 8 only 1/100 seconds.

  • Page 19: Timy3 Update

    Manual Timy3 - General Timy3 Update Please visit our website www.alge-timing.com for a free update for your Timy3 software. 6.1 Update Firmware with USB cable • If not done yet, the Timy3 USB driver has to be installed. An instruction for this can be found on our website https://alge-timing.com/download/Software/Driver/TimyUSBDriver.exe...

  • Page 20: Info Menu

    On the following pages the different menu items are described. The program specific menu settings are described in the separately available manuals for each program. Settings printed bold are the ALGE-TIMING factory settings. -20-...

  • Page 21: Classement

    Manual Timy3 - General 9.1 CLASSEMENT The ‘classement’ menu offers different options to print results. 9.1.1 Prints an overall ranking of different saved times. According to each program the following options are available: • <RUNTIME> ranking sorted according to run time •...

  • Page 22: Sec-Mode

    Manual Timy3 - General 9.2.3.2 FINISH This controls the start number continuation for competitors reaching the finish. • <MANUALLY> no automatic continuation • <START> only 1 competitor on track from start to finish • <FINISH> several competitors on track, according to starting order 9.2.3.3 AUTOMATIC-TIME Set a minimum and maximum runtime.

  • Page 23: Automatic Prog

    Manual Timy3 - General 9.2.12 AUTOMATIC PROG If <ON> is selected in the automatic program, the Timy3 always starts with the program cur- rently in use (for example Stopwatch). This feature is recommended if the user always uses the same program. 9.2.13 SYNC You can re-synchronize the Timy3 in this menu (enter new time of day).

  • Page 24: Beep

    Manual Timy3 - General Example for falling edge EDGE1: In the following diagram is dt the delay time for the falling edge (blue). Example for rising EDGE2: In the following diagram is dt the delay time of the falling edge (blue) and dt the delay time of the rising edge (red).

  • Page 25: Wtn Delay

    Manual Timy3 - General • F2 „XXX“ The status of the channel is not changed. This is only of importance for an RS232 or GSM connection with a second Timy. The channel of the other Timy is not changed. • F3 „OK“...

  • Page 26: Display

    Settings for the RS232 and scoreboard interface. Some settings are only available in certain programs. 9.5.1 DISPLAYBOARD These are settings for ALGE-TIMING displays of the type D-LINE or GAZ. • <BRIGHTNESS> adjusts the brightness (0 – 9) of the LED display board • <TIME + DATE>...

  • Page 27: Rs232

    Adjustment of line feeds after printing a data package. It is adjustable between 0 and 9. • <0> factory setting is zero 9.6.4 START-LOGO Adjustment whether the ALGE-TIMING logo is printed when switching on the Timy3. • <OFF> no logo is printed • <ON>...

  • Page 28: Program

    9.8 Program Specific Settings Depending on active program this menu item is different. The ALGE-TIMING WTN is a radio network consisting of several devices of the WTN-series. Within the network, devices can communicate with each other using other devices; i.e. the communication is carried out from one device to another through a third one.

  • Page 29: Settings

    Manual Timy3 - General Link Quality Indicator (Lqi): * ... poor link quality **..medium link quality *** ..good link quality Receive Signal Strength Indicator (Rssi): -127 ..no connection -65 ..worst receive signal strength quality +20 ..best receive signal strength quality Transmission Status: 0 to 4 ..

  • Page 30: Statistics

    Manual Timy3 - General 9.9.6 STATISTICS It shows the number of data strings that have not reached the Timy3. The data is displayed per team. 9.9.7 BROADCAST PARM It is adjustable if you want to send the adjusted WTN parameter of this Timy3 to other WTN devices in the team or not.

  • Page 31: Technical Data

    5 channels per extension, max. 99 channels Power supply: Internal: NM-TIMY2 battery pack or 6 x AA-Alkaline 2 Ah (only for Timy3 W) External: with charger PS12A, 12 V battery or 8 -24 VDC Operating time (20 °C): Alkaline: without printer about 50 hours...

  • Page 32: Pin Assignment

    Timy3 can be controlled completely and all data can be re- called. Charger Connection (2): ALGE-TIMING Multiport (3): Pin assignment: 1 ....terminal numbering connection 2 ..c0..start channel (precision 1/10,000 s) 3 ..c2..timing channel 2 (precision 1/10,000 s) 4 ..
  • Page 33 Manual Timy3 - General banana plugs for display board banana plugs for start channel C0 banana plugs for stop channel C1 Photocell socket (7) Pin assignment: 1 .... c0 ..start channel 2 .... c1 ..stop channel 3 .... GND..common ground 4 ....

  • Page 34: Interfaces

    Manual Timy3 - General 12 Interfaces 12.1 RS232 Interface Output format: 1 start bit, 8 data bit, no parity bit, 1 stop bit Bit rate: 9600 baud factory setting adjustable: 2400, 4800, 9600, 19200, 28800, 38400 Transmission protocol: ASCII yNNNNxCCCxHH:MM:SS.zhtqxGGRRRR(CR) y ........
  • Page 35 Manual Timy3 - General -35-...
  • Page 36 Manual Timy3 - General -36-...

  • Page 37: Rs485 Interface

    Terminal etc. 12.3 Interface for Display Board Output format: 1 start bit, 8 data bits, no parity bit, 1 stop bit factory setting: 2400 baud (for ALGE-TIMING GAZ display board) Bit rate: 2400, 4800, 9600, 19200, 28800, 38400 Transmission protocol: ASCII NNN.xxxxxxxxM:SSxxxx(CR) ....
  • Page 38 Manual Timy3 - General -38-...
  • Page 39 Manual Timy3 - General -39-...
  • Page 40 Manual Timy3 - General Subject to changes and misprints Copyright by ALGE-TIMING GmbH Rotkreuzstr. 39 6890 Lustenau / Austria www.alge-timing.com -40-...
