Features
Lengthened tank
Control panel with capacitive
sensing technology
Industrial grade
ultrasonic transducer
2 x colour LED display
Degas feature
Ceramic heater
Multiple circuit protectors
Cooling fan
Detachable power cord
Moisture-proofed PCB with
industrial IC
Engineering grade plastics
Professional Ultrasonic Cleaner
Tank capacity: 2500ml; Size: 24.5 x 15.0 x 7.6 cm / 9.6" x 5.9" x 3.0".
Longest item that can fit inside the tank is 26.0 cm / 10.2"
Durable, reliable, resistant to water and harsh chemicals
Ø38 industrial transducer (60W), giving 170W cleaning power
1 to 30-minute full range timer
Removes air bubbles quickly
Ceramic heater (100W), 65°C temperature limited
When overloaded or improperly used, the protectors
shut down the power to certain areas to protect the machine
To protect and keep every part in good condition after working
a long time
Independent power switch and detachable power cord
Capable for different working environments with better
anti-interference performance
4mm wall thickness with tongue and groove joints for better impact
and water-proof performances
User Manual
14/06/052-V4
Advertisement
Table of Contents
Related Manuals for James products ULTRA 8051
Summary of Contents for James products ULTRA 8051
- Page 1 14/06/052-V4 Professional Ultrasonic Cleaner User Manual Features Lengthened tank Tank capacity: 2500ml; Size: 24.5 x 15.0 x 7.6 cm / 9.6” x 5.9” x 3.0”. Longest item that can fit inside the tank is 26.0 cm / 10.2” Control panel with capacitive Durable, reliable, resistant to water and harsh chemicals sensing technology Industrial grade...
-
Page 3: Table Of Contents
SPECIFICATIONS Description Professional Ultrasonic Cleaner Model ULTRA 8051 Tank Capacity 2500ml (Max. 2100ml - Min. 600ml) Tank Size 24.5 x 15.0 x 7.6 cm / 9.6” x 5.9” x 3.0” Longest Item Fits inside Tank 26.0 cm / 10.2” Power Supply... -
Page 4: Safety Precautions
SAFETY PRECAUTIONS Keep it away from children! This appliance can be used by children aged from 8 years and above if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved. -
Page 5: Items Not Suitable For Ultrasonic Cleaning
SAFETY PRECAUTIONS Other observations: • Do not operate the product without filling the tank with water. Running dry will damage the unit. • Do not plug in the power cord before adding water to the tank. To avoid overspill, do not fill the tank above the ‘Max’... -
Page 6: Product Detail
PRODUCT DETAIL A. Top cover B. Stainless steel tank C. Top casing D. Bottom cover E. Control panel Plastic Tray F. Handles G. Power socket H. Power switch Power Cord... -
Page 7: Control Panel And Operations
CONTROL PANEL AND OPERATIONS 1. Indicator Light - Working Status. Green - Normal working status, ready to use. Red - Under overheat protection. 15 minutes or more of waiting time is needed for the light to change from red to green. Work can resume afterwards. 2. -
Page 8: Sample Applications
SAMPLE APPLICATIONS JEWELLERY PERSONAL ITEMS MEDICAL / DENTAL Necklaces, rings, Shaver heads, watch bands, Surgical instruments, earrings, bracelets, etc. diver’s watches, dentures, etc. pliers, handpieces, etc. PRECISION PARTS SILVER, COPPER OR BRASS BABY ITEMS Bearings, gears, valves, Silverware, silver, copper or Toys, baby items, tools, fuel injectors, etc. -
Page 9: Applications
APPLICATIONS 1. Metal Processing Manufacturers and Jewellery Makers: - Ultrasonic cleaning can remove grease or abrasive powder from work-in- process metal items and keep them clean. - Jewellery made with investment casting often has wax layer in addition to debris. Turning on the heater will raise the water temperature, melt the wax and improve the cleaning. - Page 10 APPLICATIONS 7. Shooting Clubs To reuse brass cartridges: Adding special solution such as SeaClean2 solution can make fired brass casings useable and like new again. Gun cleaning and care: Cleaning guns after shooting is time consuming. Using SeaClean2 solution in the water and using ultrasonic cleaners can complete the cleaning better, quicker and easier than traditional methods.
- Page 11 APPLICATIONS 12. Homes: Silverware, silver, copper or brass decorations: It’s difficult to clean debris hidden in the patterns with regular methods. Ultrasonic cleaning with 50ml (3 tablespoons) of dish soap will clean the debris quickly. For silver, copper or brass items with oxidation which has darkened the items, adding small amount of SeaClean2 solution helps to remove oxidation and using ultrasonic cleaning will restore the shine.
-
Page 12: Common Cleaning Methods
COMMON CLEANING METHODS REGULAR CLEANING Only tap water is needed. Suitable Locations: Jewellery makers, optical labs, biology / chemical labs, homes, speech therapy clinics, dental clinics. Cleaning Method: 1. Put the items to be cleaned onto the tray and put the tray inside the tank. - Page 13 ENHANCED CLEANING Debris accumulated over a long period of time, greasy or heavily soiled. Suitable Locations: jewellery makers, homes, automotive repair shops. Cleaning Method: 1. Put the items in the cleaning tank directly. Do not put the items on top of each other to avoid rubbing during cleaning. 2.
-
Page 14: Operation Guidelines
OPERATING GUIDELINES Remove the lid, put the items onto the tray then put them in the cleaning tank. Add water to a level between “MIN” and “MAX” and above the area to be cleaned. If the unit is turned on without water, ultrasonic energy will not be absorbed. -
Page 15: Care And Maintenance
When cleaning is completed, unplug the power cord, remove the lid and retrieve the items. Pour the water out through the pouring recess. Clean and wipe the tank dry. CARE AND MAINTENANCE Do not turn on the unit without water in the tank. Even though the unit is designed with multiple protections, if it is turned on for over 30 seconds without water in the tank, it may damage the unit or severely reduce the life of the unit. - Page 16 *Repair or replacement is at the discretion of the manufacturer. www.jamesproducts.co.uk Registered in England No. 5250754 Registered Office: James Products Ltd, Unit 1, Church Close Business Park, Todber, Sturminster Newton, Dorset DT10 1JH, England...
