Red Leopard Orbit Operating Manual page 5

STEP 5: CONNECTING & USING THE FLOW CONTROL VALVE
The Flow Control Valve ensures your
to ensure optimum performance.
•Make sure the pool pump is turned OFF.
•
Expel all the air from the hose.
•
Attach Flow Control Valve to the male hose
(smaller end) . See Fig 6.
•
Insert the Flow Control Valve into the
Weir/Skimmer. If necessary, use the Control
Valve Adaptor to ensure a good connection.
See Fig 7.
•
Turn the pool pump ON.
•
Your Orbit pool cleaner will now begin
automatically vacuuming your pool.
The Flow Control Valve is preset
between
position
ideal operating flow in most pools But if
,
necessary the flow can be adjusted by
using any setting from Position
6 (1=
through minimum flow, to slow
your cleaner down
your cleaner will run faster See Fig 8.
3-4.
This provides the
.
1
, 6 =
maximum flow,
).
Orbit pool cleaner receives the flow required
Figure 7
Flow Control Valve
Figure 8
Figure 6
Attach Male
Hose Adaptor
(smaller end)
Flow Control
Valve
Control Valve
Adaptor
Top of Skimmer
Hose through
Skimmer
Opening
Control Valve
Adaptor
Press into bottom
of skimmer
Attach
Hose This
End
PAGE 5
