20' x 50' Titan Series pole tent single piece top
instruction and owner's manual
20 x 40 shown
Note: 20 x 40 shown
Important: Read this manual before installation or use of this
product. Failure to do so can result in serious personal injury or
damage to the product. RETAIN THIS MANUAL!!
Notice to all installers and users
The following instruction manual is provided as a guide to installers and
users. The situations and conditions described in this manual cannot
represent all situations that may be encountered during the installation or
dismantling process. The use of common sense, good judgment, and safe
practices must be followed to prevent injury and damage to the product.
Equipment/manpower for installation
*Ground cloth, sledge hammer or breaker hammer fitted with stake driver
bit and stake puller.
*A minimum of (3) adults are required for installation
*Sit down (round tables) = 100 persons
*Cathedral (row) seating = 160 persons
*Stand up / cocktail = 200 persons
Tent occupancy guidelines
Advertisement
Table of Contents
Related Manuals for DREMCOR Titan Series
Summary of Contents for DREMCOR Titan Series
- Page 1 20’ x 50’ Titan Series pole tent single piece top instruction and owner’s manual 20 x 40 shown Note: 20 x 40 shown Important: Read this manual before installation or use of this product. Failure to do so can result in serious personal injury or damage to the product.
-
Page 2: Contents Of This Manual
Contents of this manual Personal safety Product specifications Hardware (what’s included) Weather conditions Installation site 20’ wide (1) pc top pole tent anchoring and staking Installation procedure Tent dismantling Maintenance and Care Warranty Information Personal safety Personal safety must be practiced during the installation process to avoid injury to yourself and others. - Page 3 20’ x 50’ Titan Series pole tent specification sheet Feature Specification Note Style / Series Traditional / Titan Series Pole supported tension tent Width 20 ft / 6.1 m Length 50 ft / 15.2 m Total height 14 ft / 4.27 m...
- Page 4 20’ x 50’ Titan Series pole tent hardware package (what’s included) Symbol Item Size/length Quantity Diagram/description Side and corner 7’ or 8’ long (not Poles may be aluminum or galvanized depending poles (bottom is including 10” pin on customer order...
-
Page 5: Weather Conditions
*Contact all related underground utility “call before you dig” authorities prior to staking. *Note: Dremcor LLC assumes no responsibility for the method of installation that the installer chooses or the failure to contact the proper authorities as noted above. Each state, county, township or city may have unique temporary structure installation codes and requirements so it is important that the proper codes &... - Page 6 Option #2: Stake inserted to double D ring S hooks can be installed to the white plate Dremcor has both strap options available for purchase. Dremcor has both strap options available for purchase Double D ring option eliminates noose forming and...
-
Page 7: Installation Procedure
Installation procedure Ground cloth and tent top preparation *Layout a ground cloth or protective tarp in the location where the tent will be installed. The ground cloth should be larger in area than the tent top to offer complete protection for the tent top (see diagram below) *Remove the tent top from the storage bag and unroll onto the ground cloth. - Page 8 Installation procedure (continued) Stake and ratchet preparation *Attach the S hook strap or 8’ loop strap (strap without the ratchet buckle) to the white aluminum plates at each corner and side location. Note that (2) loop straps will be installed on each corner. Turn the loop strap inside out and pull the strap thru the loop to create a noose and pull tight (see anchoring and staking page for additional options and photos).
- Page 9 Installation procedure (continued) Pole installation *Layout the corner and side poles around the perimeter of the tent top in the brass grommet locations. DO NOT PLACE THE POLES ON THE TENT TOP. *Insert the corner pole pin thru the white aluminum plate on the underside of the tent top and thru the brass grommet at each corner location.
- Page 10 Installation procedure (continued) *Insert the center pole pin thru the top of the center white aluminum plate and the brass grommet. CARE MUST BE TAKEN IN THIS STEP SO THE PIN DOES NOT DAMAGE THE TENT TOP. *Lift the center pole and move the bottom toward the center of the tent while leaving at an angled position (see diagram below) *Tie off the center pole jump rope that is attached to the center aluminum plate.
-
Page 11: Maintenance And Care
Maintenance and care Dremcor provides high quality products that can last for many years of use. Failure to maintain and care for the tent top can result in premature wear and degradation. The following procedures are strongly recommended to maintain your product.
