Summary of Contents for Eclipse 902-544
- Page 1 Instruction Manual Hydraulic Crimping Tool 902-544 Due to continuing improvements, actual product may differ slightly from the product described herein. Read this material before using this product. Failure to do so can result in serious injury. SAVE THIS MANUAL...
- Page 2 SAVE THIS MANUAL LIMITED 1 YEAR WARRANTY Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the month and year of We make every effort to assure that its products meet high quality and durability standards, purchase.
- Page 3 Description Description GENERAL SAFETY RULE single-direction valve body fixed handle drum spring protection cover TO WORK IN SAFE CONDITIONS WITH THIS TOOL, IT IS IMPERATIVE TO READ CAREFULLY THE DIRECTIONS FOR USE AND TO FOLLOW THE INSTRUCTION steel ball C5 fixed handle sleeve IT CONTAINS.
- Page 4 of untrained users. Description Description Maintain power tools. Check for misalignment or binding of moving parts, hexagon scrtew M5×30 pressure release pin breakage of parts and any other condition that may affect the Hydraulic crimping tool operation. If damaged, have the Hydraulic crimping tool repaired before use. hexagon scrtew M6×30 pin 7X29.5 Many accidents are caused by poorly maintained power tools.
- Page 5 Parts list SPECIFIC SAFETY RULES Maintain labels and nameplates on the tool which carry important safety information. If unreadable or missing, contact the agent to replace. This product is not a toy, keep it out of reach of children. Do not slide your fingers in the dies profile. Do not crimp on live cables or conductors Do only crimp copper or aluminum conducting material The warnings, precautions, and instructions discussed in this instruction manual...
- Page 6 UNDERSTAND YOUR TOOL FAULT ANALYSIS SOLUTION Fill the oil 902-544 is a non-interchangeable crimping tool, suitable for crimping tubular cable lugs A. No pressure or the The pump lacks oil Change the oil pressure is not enough There is dust in oil and connectors, standard type and tubular cable lugs.
- Page 7 Code Name Function MAINTENANCE AND SERVICING for crimping, unchangeable crimping die Head for holding die Damaged equipment can fail, causing serious personal injury. Do not use damaged Limited pin for preventing head from excessive rotating equipment. If abnormal noise or vibration occurs, have the problem corrected before further use.
- Page 8 Please refer to the illustration below. OPERATING INSTRUCTIONS. Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Please do not knock any parts of the tool, otherwise it is dangerous for the operator.
