Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com
Instruction Manual
Battery Crimping Tool 902-484
Due to continuing improvements, actual product may differ
slightly from the product described herein.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 902-484 and is the answer not in the manual?

Questions and answers

Related Manuals for Eclipse 902-484

Summary of Contents for Eclipse 902-484

  • Page 1 Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com Instruction Manual Battery Crimping Tool 902-484 Due to continuing improvements, actual product may differ slightly from the product described herein. Read this material before using this product.

  • Page 2: Limited 1 Year Warranty

    LIMITED 1 YEAR WARRANTY We make every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of one year from the date of purchase (90 days if used as rental equipment).

  • Page 3: Important Safety Information

    SAVE THIS MANUAL TROUBLESHOOTING Keep this manual for the safety warnings and precautions, assembly, operating, inspection, FAULT ANALYSIS SOLUTION maintenance and cleaning procedures. Write the month and year of purchase. Keep this manual and the receipt in a safe and dry place for future reference. Dirt, contaminants, etc in ram area of tool.

  • Page 4: General Safety Rules

    GENERAL SAFETY RULES j. If the tool not used for a long time, please make sure the piston stays on its starting position, clean up the tool and rub rustproof oil both to the tool and accessories. Take out the battery and put it into the box and store the tool in a dry surrounding. TO WORK IN SAFE CONDITIONS WITH THIS TOOLING, IT IS IMPERATIVE TO READ CAREFULLY THE DIRECTIONS FOR USE AND TO FOLLOW THE INSTRUCTIONS IT CONTAINS.

  • Page 5: Maintenance And Servicing

    The best temperature for charging is between 10℃-40℃. Make sure the air hole of the battery and charger are uncovered during charging. Please cut off the power of the charger each time to reduce the hazard from child or the person who not expert on the tool. Do not wait until the battery runs over for recharging, the recharging will caused the battery does not working anymore.

  • Page 6: Specific Safety Rules

    4. Service Have your Battery Crimping Tool serviced by a qualified service technician using only identical replacement parts. This will ensure that the safety of the Battery Crimping Tool Kit is maintained. SPECIFIC SAFETY RULES Maintain labels and nameplates on the tool which carry important safety information. If unreadable or missing, contact the agent to replace.

  • Page 7: Specification

    3 s to turn on the power, the tool will self-test for 1 s, the data showing the last record, the tool is ready to work. 902-484 is a tool for crimping Cu lugs with cables from 16-400 mm . It is powered by Li-ion, actuated by motor and controlled by MCU.

  • Page 8: Description Of Components

    Set the output Press for 3 s enter into setting status, the data display 2. Description of components: force will flash. Press the per time, output data increase by 10 KN (1Ton) (or 5 KN (1.2 Ton), according to requirement), this action is circulated from Min KN to Max KN.

  • Page 9: Function Description

    Function description The battery can be charge cycled hundreds of times, when the charge time is reduced MCU –automatically detect the pressure during operation and provide considerably, change to a new battery. Security protect, shut off the motor and reset automatically after Please charge the battery in time to avoid it to be used up completely;...
  • Page 10 sounds, it means the tool can’t continue working until the temperature OPERATING INSTRUCTION reduced to normal. Micro computer control system with the feature of self-pressure detecting, Read the entire SAFETY INFORMATION section at the beginning of this manual double protection during operation, counting and realize the exchange including all text under subheadings therein before using this product.
