Summary of Contents for Volvo XC 90 EXCELLENCE 2018

  • Page 2: Mobile App

    VÄLKOMMEN! Here you can read about the functions for the rear seat in your Volvo XC90 Excellence. More detailed owner's information is available in the car, in the app and on the web. THE CAR'S CENTRE DISPLAY The owner's manual is available in the car's centre display, where it can be accessed via the top view.
  • Page 3 CONTROL DISPLAY IN THE REAR SEAT The control display is fitted in the tunnel console between the rear seats and it controls the seat functions as well as the heating and cooling of drinks. Raising the screen – Press the top of the screen. The screen rises automatically. The screen starts automatically when it is raised.
  • Page 4 NAVIGATING IN THE CONTROL DISPLAY The control display is a touch screen that reacts to touch. The display consists of different views. Tap on a button in the screen to activate Button for adjusting the front passenger seat from the the desired function or to access the view for a function.
  • Page 5 ADJUSTING THE REAR SEAT The car's rear seats have different setting options for optimum seating comfort. Adjust the backrest rake by adjusting the control forward/backward. Raise/lower the seat by means of adjusting the rear section of the control up/down. Move the seat forward/backward by adjusting the control forward/backward.
  • Page 6 OPERATING THE MULTI-FUNCTION CONTROL Use the multi-function control to adjust lumbar support, side bolsters in the backrest, seat cushion length as well as massage settings. Settings made with the multi-function control are shown in the control display. The screen only shows the settings of one seat at a time. 1.
  • Page 7 Lumbar support Tap on the screen button or select the function with the multi-function control to activate adjustment of lumbar support. • Press the seat button up/down on the multi-function control to move the lumbar support up/down. • Press the front section of the seat button to increase lumbar support.
  • Page 8 ADJUSTING THE FRONT PASSENGER SEAT FROM THE REAR SEAT Adjusting longitudinally The front passenger seat can be adjusted from the rear seat for longitudinal position and the backrest rake can be changed. Use the • Tap on the lower left-hand arrow to move the front passenger seat control display between the rear seats to change the settings of the forward.

  • Page 9: Heated/Ventilated Seats

    HEATED/VENTILATED SEATS The seats can be heated in order to increase comfort when it is cold. The seat heater is controlled from the control display. – Tap repeatedly on the button for the left or right-hand seat to change between the four levels: off, high, medium and low.
  • Page 10 MOUNTING POINTS FOR CHILD SEATS The car is equipped with mounting points for child seats in the rear seat row. The upper mounting points are primarily intended for use with front-facing child seats. 1. Slide the seat forward and fold the backrest forward in order to access the mounting point.

  • Page 11: Cooler Box

    COOLER BOX There is a cooler box behind the armrest in the rear seat with space for two bottles and storage spaces for the crystal glasses. • Press the button located above the cover to open the box. • On the inside of the box there is a control for setting the temperature.
  • Page 12 USB PORT AND ELECTRICAL SOCKET LOCATIONS USB ports: There are two USB ports under the armrest in the rear seat. The screen brackets on the rear of the front seat head restraints also include two USB ports. The ports can be used to e.g. charge a mobile phone or tablet.

  • Page 13: Storage Spaces

    STORAGE SPACES There are holders on the rear of the front seat head restraints for tablets. There is a storage space under the armrest between the seats. There are ashtrays in the door sides. There are storage compartments in the door sides. There are storage pockets on the sides of the tunnel console.
  • Page 14 HANDLE IN THE CARGO AREA The car is equipped with a self-illuminating handle on the inside of the tailgate. It can be used to open the tailgate from the inside in an emergency situation. – Pull down the handle to open the tailgate. After use, the handle must be pressed back into its original position manually.

  • Page 15: Special Texts

    SPECIAL TEXTS Ventilated rear seats by people sensitive to draughts. A low level is The seat ventilation cannot be started if the recommended for long-term use. passenger compartment temperature is too The owner's manual and other manuals contain low. This to avoid making it too cold for the seat safety instructions and all warning, important and occupant.
  • Page 16 TP 24518 (English) AT 1709, MY17. Printed in Sweden, Göteborg 2017, Copyright © 2000-2017 Volvo Car Corporation...
