: press to exit menu, application, function.
: press to go to main screen/main menu.
: press, to give a command to the Google Assistant voice assistant.
: press to increase or decrease the volume.
Attention: All pictures in this manual are examples, only for reference, actual
product may differ from the pictures and graphics.

5. Basic Operations

AV cable
RJ45 socket in
the router

5.1 Connecting to an image receiver

The device can be connected to different image receivers. It could be TV
receiver.
We recommend using modern TVs, monitors and projectors with an image
resolution of at least HD Ready / 720p (1280x720 points).
TV
LAN RJ45
cable
22
Flix TV BOX - EN
Power
HDMI
cable
