Summary of Contents for Brunetti MC2 MASTER COMBO
-
Page 2: Technical Specifications
CONGRATULATION FOR YOUR CHOICE! TECHNICAL SPECIFICATIONS - All tube path signal - External speaker connection - Three band equalization - Pre - Gain and Bright Eq. for the Clean Channel - Separated post Gain and Master Eq. for the Crunch/Lead channels - Spring reverb (Accutronics) with buffered solid state amplifier - Spring reverb separated controls for all the channels - EDG function with all tube ''Harmonic Shape Mirror''... -
Page 3: Front Panel
FRONT PANEL CLEAN GAIN: Amplification Bright: More brilliant sound BASS: 100Hz Bass MID: 600Hz Mid 3KHz High CRUNCH GAIN: Amplification BASS: 120Hz Bass MID: 600Hz Mid 2KHz High MASTER: Pramplified signal LEAD GAIN: Amplification BASS: MID: Same control of Crunch MASTER: Pramplified signal REV.CLE: Reverb volume of the Clean channel... - Page 4 REAR PANEL On the rear panel there is a Loop section that allows you to mix the original sound of the combo with your effect, at 50%. The Send has been studied to serve stomp efx and rack efx, to obtain always the maximum sound result. The Send level depends by the volume control level of the two channels.
-
Page 5: Power Amp
REAR PANEL HOW TO USE THE SEND In the normal use the SEND output can be used to connect an external power amp and its cabinet together to the combo. (See example). Select on the power amp the same impedance value POWER AMP of the cabinet (in this example 16 ohm). - Page 6 FRONT PANEL - CONTROLS ATTENTION!! To replace the The REV knobs HT fuse use a control the level of SB (slow blow) reverb for the CEAN The DRIVE knobs type with the control the Gain or CRUNCH/LEAD same value. This knob controls the channels.
- Page 7 SUGGESTED CLEAN SETTING REVERB REVERB CLEAN BASS HT fuse VOLUME DRIVE DRIVE MASTER MASTER DRIVE DRIVE MASTER MASTER CLEAN BRIGHT CRUNCH/LEAD CRUNCH/LEAD CRUNCH CRUNCH LEAD LEAD STANDBY POWER EDGE BASS BASS REVERB REVERB CLEAN BASS HT fuse VOLUME DRIVE DRIVE MASTER MASTER DRIVE...
- Page 8 SUGGESTED LEAD SETTING REVERB CLEAN CLEAN BASS BASS HT fuse VOLUME VOLUME DRIVE DRIVE MASTER MASTER DRIVE MASTER CLEAN CLEAN BRIGHT BRIGHT CRUNCH/LEAD CRUNCH CRUNCH LEAD STANDBY POWER EDGE BASS REVERB CLEAN CLEAN BASS BASS HT fuse VOLUME VOLUME DRIVE DRIVE MASTER MASTER...
- Page 9 SUGGESTED CRUNCH SETTING REVERB CLEAN CLEAN BASS BASS HT fuse VOLUME VOLUME DRIVE MASTER DRIVE DRIVE MASTER MASTER CLEAN CLEAN BRIGHT BRIGHT CRUNCH/LEAD CRUNCH LEAD LEAD STANDBY POWER EDGE BASS REVERB CLEAN CLEAN BASS BASS HT fuse VOLUME VOLUME DRIVE MASTER DRIVE DRIVE...
-
Page 10: General Information
GENERAL INFORMATION PREAMP TUBES The preamp tubes are used to preamplifier the signal. They usually last the entire life of the amplifier. The possible problems of these kind of tubes are: microphonics and noise. Microphonics The microphonics is the ability of a tube to reproduce external vibrations further the signal. This phenomenon can be much more evident in high gain stage like the distortion channels. - Page 11 GENERAL INFORMATION SYNTHESIS EFFECTS The main characteristic of the synsthesis effect (see example) is to modify the signal wave form. (i.e. the distortion effects). This kind of effect should be used between the guitar and the input of your amp, in a standard connection chain. MODULATION EFFECTS The main characteristic of the modulation effect (see example) is to add and/or lay other wave forms to the signal.
- Page 12 − In case of damage contact the shop where you bought the appliance. − The appliance must be earthed in conformity to the national previsions in force. For any further information and/or support contact us. Brunetti Marco & C. S.a.s Via Deí Bonomini, 25/27 I - 41100 MODENA - ITALIA Phone number : +39 059 / 243404 http://www.brunetti.it...
