Component list
FOLD ARM(×1)
A
TUBE
L400(×1)
E
WASHER
12.5*
25*
T=3(×3)
1
BRAKE SCREW
ALLEN WRENCH
M6*P1.0
*L6mm(×2)
5
or
C
D
9
JOINT(×1)
B
BASE(×1)
F
WASHER
SPRING WASHER
8*
13(×3)
2
ALLEN WRENCH
NO.3(×1)
6
To install LCD Mount(C) in the back of monitor:
Locate mounting screw fixtures on the back
of monitor and attached LCD mount(C OR D)
with screw(9).
Make sure the screw(9) match to your monitor
hole to fix the LCD Mount(C OR D).
LCD MOUNT
76mm(×2)
C
CABLE CLIP(×1)
G
NYLON NUT
5/16"(×3)
5/16"(×3)
3
WRENCH
NO.4(×1)
NO.13(×1)
7
LCD MOUNT
82mm(×1)
D
FOR LCD monitor
4
SCREW
M4*P0.7*
L12mm(×12)
9
8
EL-026
Advertisement
Related Manuals for Elitech EL-026
Summary of Contents for Elitech EL-026
- Page 1 Component list EL-026 FOLD ARM(×1) JOINT(×1) LCD MOUNT LCD MOUNT 82mm(×1) 76mm(×2) TUBE BASE(×1) CABLE CLIP(×1) L400(×1) FOR LCD monitor WASHER SPRING WASHER NYLON NUT WASHER 13(×3) 5/16"(×3) 5/16"(×3) 12.5* T=3(×3) SCREW M4*P0.7* L12mm(×12) BRAKE SCREW ALLEN WRENCH ALLEN WRENCH WRENCH M6*P1.0...
- Page 2 Assembly steps STEP 1 STEP 2 Installing Tube(E) on the base(F) and Put the Fold arm(A) and Joint(B) through then put on the Cable clip(G) on the the Tube(E). tube for cable management. To adjust the height of Fold arm(A) and Fixed the brake screw(3) with Allen Joint(B) with Allen wrench(7).
