1302 W
B
A
• P.O. B
1127 • E
IN 46515 • (574) 295-8330 • F
(574) 293-9914
EST
EARDSLEY
VENUE
OX
LKHART
AX
Operating and Maintenance Instructions
SFL-BG (RNZN)
Combination Type Nozzle
With Detent At Narrow Fog
98448000 REV-A
Advertisement
Table of Contents
Related Manuals for ELKHART BRASS SFL-BG
Summary of Contents for ELKHART BRASS SFL-BG
- Page 1 1302 W • P.O. B 1127 • E IN 46515 • (574) 295-8330 • F (574) 293-9914 EARDSLEY VENUE LKHART Operating and Maintenance Instructions SFL-BG (RNZN) Combination Type Nozzle With Detent At Narrow Fog 98448000 REV-A...
- Page 2 Table Of Contents Product Safety………………………………………………………………………………………………..1 Nozzle Operation…………………………………………………………………………………………….2 Maintenance………………………………………………………………………………………………..3 IV Assembly Drawing…………………………………………………………………………………………….4...
- Page 3 Product Safety Important: Before installing and operating this equipment, read & study this manual thoroughly. Proper installation is essential to safe operation. In addition, the following points should be adhered to in order to ensure the safety of equipment and personnel: •...
- Page 4 Nozzle Operation Flow Capabilities This nozzle has been designed to exhibit the following flow characteristics: • Maximum Working Flow 95 GPM (360 LPM) at a Maximum Working Pressure of 100 PSI (6.9 BAR) Ball Shutoff This nozzle has been equipped with a ball shutoff. The nozzle can be shut off by pushing the horseshoe handle forward, away from the user.
- Page 5 (28) can be removed from the nozzle assembly. These parts can be seen in the following assembly drawing. Use an Elkhart Brass Seat Wrench (P/N 71251000) to adjust the seat until the desired tightness is achieved. Reassemble the nozzle. Be sure to apply thread locker (Loctite #242 or equivalent) to the...
