CO-Melder
CO detector
BCN 1221
Bedienungsanleitung ...................... 2
Directions for use.......................... 19
Mode d'emploi ................................ 35
Handleiding ...................................... 52
Istruzioni per l'uso ........................ 69
Bruksanvisning .............................. 86
Manual de instrucciones .......... 101
Instrukcja obsługi ...................... 118
Advertisement
Table of Contents
Related Manuals for brennenstuhl BCN 1221
Summary of Contents for brennenstuhl BCN 1221
- Page 1 CO-Melder CO detector BCN 1221 Bedienungsanleitung ...... 2 Directions for use......19 Mode d’emploi ........ 35 Handleiding ........52 Istruzioni per l’uso ......69 Bruksanvisning ......86 Manual de instrucciones ..101 Instrukcja obsługi ...... 118...
-
Page 2: Table Of Contents
Operating Instructions Battery-Powered CO-Detector BCN 1221 Important: Read these operating instructions and keep them. Make note of and follow the safety notices. Table of Contents Battery Powered Carbon Monoxide (CO) Detector 1. Introduction ............20 2. Package contents ..........20 3. Technical data ............21 4. -
Page 3: Introduction
Immediately after unpacking the contents of your detector’s package must be checked for complete- ness. Also check the detector itself for proper con- dition. 1 x CO-detector BCN 1221 1 x 9 Volt block battery 2 x screws 2 x anchor bolts... -
Page 4: Technical Data
BCN 1221 Operating Instructions 3. Technical data The CO-detector is calibrated so that it sounds in response to the following CO-values, in compliance with EN 50291:2001. CO concentration No alarm Alarm in the air before before 30 ppm 120 min. - Page 5 Operating Instructions BCN 1221 WARNING! This detector is only intended for use in dry rooms. Use outdoors or in moisture-prone rooms is not permitted. In order to assure the protective function of the detector, the LED POWER must be checked at regular intervals (see the table Alarm Signals and LED-Display).
-
Page 6: Operation And Mounting
BCN 1221 Operating Instructions 4. Operation and Mounting In this chapter, the basic functions of the detector are explained. Read through this chapter carefully so that you understand and can use all functions. 4.1 Selection of the Mounting Site WHERE SHOULD THE CO-DETECTOR BE... -
Page 7: Locations To Avoid
Operating Instructions BCN 1221 The density of carbon monoxide is close to that of air (0.96716) at a room temperature of 20ºC. It disperses in the air easily, like perfume, evenly in all directions. However, carbon dioxide is heavier than air at 0ºC (density of 1.250). -
Page 8: Installation And Set-Up
BCN 1221 Operating Instructions • In direct sunlight, directly over a sink or cooking device. • Behind curtains, drapes, furniture or locations where there is no air circulation. • In unheated basement rooms and garages. • In locations where the detector could be exposed to chemical solvents or cleaners. - Page 9 Operating Instructions BCN 1221 The CO-detector should be installed by a professional. After the battery has been installed, the green LED “POWER” will blink 1x green once for indica- tion. Wait about 1 minute until the detector has set itself up. Then test the detector by pressing the “test and hush”...
- Page 10 BCN 1221 Operating Instructions ALARM SIGNAL & LED- DISPLAY Note: means “peep, peep, peep” ■ ■ ■ Detektor function Green Yellow Alarm Sond Energy display Alarm signal Fault signal Power Alarm Fault Normal operation Blinks once per Minute ☼ Alarm condition 4 peeps + ■...
-
Page 11: Additional Functions
Operating Instructions BCN 1221 4.4 Additional Functions The CO-detector is provided with the following additional user-friendly functions: Alarm function: This function is used to turn off the alarm for 4 minutes. Press the “Test/Hush” button on the alarm. If the CO-concentration reaches 200 ppm (parts per million), the alarm will reactivate. - Page 12 BCN 1221 Operating Instructions will be stored for 12 hours. The indication that an alarm incident has occurred and is recorded in the memory function is given by a short peep every 8 seconds. The user can reset/deactivate the memory function by pressing the test button until an alarm sounds.
-
Page 13: What To Do In Case Of Alarm
Operating Instructions BCN 1221 4.5 What to do in case of alarm NEVER IGNORE THE CO-ALARM CO is called the »silent killer« because it is an invisible, odourless and tasteless gas. It arises from the incomplete combustion of fossil fuels. - Page 14 BCN 1221 Operating Instructions 6. Consult a qualified technician to localise the CO source. Extreme CO-concentrations can cause permanent injury, lead to impairment or death. COMMON RISKS WHICH CAN LEAD TO CO-POISONING • Technical problems with the device, caused by a fault, inadequate maintenance or care.
-
Page 15: Function Check/-Test
Operating Instructions BCN 1221 4.6 Function check/-test Important: The function test must be performed weekly. Check to make sure that the green LED blinks at one-minute intervals. This assures that the detector is operationally ready. If the green LED does not blink every minute or the detector does not react to the test button: 1. -
Page 16: Disposal
BCN 1221 Operating Instructions • Wipe off the alarm’s surface with a damp cloth. • Never use cleaning solutions, since this can damage the sensor. • Test the alarm after cleaning. • Check to see if the green LED “POW- ER”... -
Page 17: Guarantee
Operating Instructions BCN 1221 about options for the environmentally sound and proper disposal of the product. 7. Guarantee We grant a 3 year guarantee on this article. Repairs must be done by authorised dealers. Damages from improper use, disregarding the operating instructions and parts subject to wear are excluded from the guarantee.
