Blinc MINI-S7 Quick Reference Manual

Helmet communication system

Advertisement

Available languages

Available languages

E n g li sh - I ta lia n o
MIN I - S 7
Q ui ck Re ference M an ual
H e l me t Com mu n i cat i on Sy stem

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MINI-S7 and is the answer not in the manual?

Questions and answers

Mónica
April 19, 2025

Onde fica a entrada USB para carregar o auricular?

1 comments:
Mr. Anderson
May 10, 2025

The USB charging port for the Blinc MINI-S7 earbud is located on the device and can be accessed to connect the supplied USB cable to a computer or power adapter for charging. The exact physical location on the earbud is not specified in the provided information.

This answer is automatically generated

Summary of Contents for Blinc MINI-S7

  • Page 1 E n g li sh - I ta lia n o MIN I - S 7 Q ui ck Re ference M an ual H e l me t Com mu n i cat i on Sy stem...
  • Page 2 Bluetooth® Introduction This headset is a portable headset solution based on Bluetooth® wireless technology. Bluetooth® wireless technology is a short- range radio communication technology intended to replace the cables connecting electronic devices. The technology uses a globally available frequency range intended to ensure communication compatibility worldwide.
  • Page 3 external areas of the helmet are waterproof, you are advised to ensure the inside elements of the Bluetooth® device are not exposed to water or any other foreign substance. Any warranty does not cover the battery and in all cases will be void should it be deemed that the user has caused a malfunction or in any way tampered with the Bluetooth®...
  • Page 4 Bluetooth® Headset Control Buttons Multi Function Button VOLUME VOLUME VOLUME VOLUME DECREASE INCREASE BLUE LED RED LED Power on Press MFB button about 2 seconds, blue led flash and prompt “Power on”. Power off Press MFB button about 5 seconds, red led flash and prompt “Power off”.
  • Page 5 hear a voice prompt saying “Pairing” in the speakers. Enable your Bluetooth function on your mobile phone. Your mobile phone will now scan nearby devices and find a device named “BLUETOOTH HELMET”. Please allow your mobile phone to pair with this device. When pairing has completed and the headset is ready to use, you will hear a voice prompt from the headset saying “Pairing successful”...
  • Page 6 phone”. After second Bluetooth device or mobile phone confirms that pairing has completed, select the headset in the list of the devices on your first Bluetooth device or mobile phone. The headset is ready to be used for two Bluetooth devices or mobile phones.
  • Page 7 Intercom: FIRST STEP VOLUME VOLUME DRIVER & PASSENGER SETTING SEEKING MODE Make sure the headset is in power off position. Press and hold MFB button for at least 5 seconds. SECOND STEP VOLUME VOLUME DRIVER & PASSENGER SETTING BLINKING: LED flashes in red and blue alternately.
  • Page 8 THIRD STEP VOLUME VOLUME DRIVER SETTING CONNECT Press and release immediately MFB button, wait until the red Led stop blinking. PASSENGER SETTING CONNECT Do nothing, wait for Driver Connection, after this the red Led stop blinking. Helmets are now ready for intercom use: intercom connection will be established between the two helmets automatically by either driver or passenger by pressing the MFB button once;...
  • Page 9 Start/End intercom Press MFB button to start or end the intercom. Voice Dial Rotate the MFB button twice clockwise. Last number redial Rotate the MFB button twice anticlockwise. Answer a Call When the headset ring, you can press MFB button to answer the call or the headset will automatically answer after 8 seconds.
  • Page 10 Previous or Next song Previous song: Turn the MFB button clockwise and hold about 1 second, and then realese the button to go to the previouse song. (Some mobile phones/music players only replay the playing music ) Next song: Turn the MFB button anticlockwise and hold about 1 second, and then release the button to go to the next song.
  • Page 11 “Battery low”. Charging the headset You can charge the headset by connecting the supplied USB cable into a computer USB port or USB wall charger. LED indicator shows stable red while the device is charging and LED indicator turn off when battery is fully charged.
  • Page 12 NOTES:...
  • Page 13 I t a li a no MIN I - S 7...
  • Page 14 Il sistema BLiNC™ integrato nel vostro casco è composto da un modulo sigillato che contiene la scheda con  i  chip  elettronici  e  la  batteria  al  litio, ...
  • Page 15 nella  parte  posteriore del casco, due altoparlanti stereo, un microfono e la rotella di comando esterna, oltre che dai cavi di collegamento. Vedi la Figura 1 qui sotto. Attenzione: Non bagnare il modulo sigillato, né il carica batteria. Ascoltare musica ad alto volume da altoparlanti situati presso l’orecchio, può...
  • Page 16 Bluetooth® Headset Control Buttons Pulsanti Multi Funzione DIMINUIRE AUMENTARE VOLUME VOLUME VOLUME VOLUME LED BLU LED ROSSO Accensione Premere il pulsante PMF per circa 2 secondi, vedrete il LED blu lampeggiare e il dispositivo si accenderà. Spegnimento Premere il pulsante PMF per circa 2 secondi, vedrete il LED rosso lampeggiare e il dispositivo si spegnerà.
  • Page 17 dopodichè udirete “pairing” negli auricolari. Abilita la funzione bluetooth sul tuo cellulare. Il telefono scansionerà i dispositivi vicini e troverà un dispositivo chiamato “BLUETOOTH HELMET”. Associate il cellulare a questo dispositivo. Il led rosso smetterà di lampeggiare, mentre quello blu continuerà a lampeggiare più lentamente. Al termine dell’operazione si sentirà...
  • Page 18 Intercom: PRIMO PASSO VOLUME VOLUME IMPOSTAZIONI PER PASSEGGERO E PILOTA ATTIVARE MODALITA’ CONNESSIONE: Assicurarsi che il modulo sia spento. Tenere premuto per almeno 5 secondi il pulsante PMF. SECONDO PASSO VOLUME VOLUME IMPOSTAZIONI PER PASSEGGERO E PILOTA MODALITA PARING: I LED blu e rosso lampeggiano.
  • Page 19 TERZO PASSO VOLUME VOLUME PILOTA CONNESSIONE: Premere e rilasciare immediatamente il pulsante PMF, aspettare qualche secondo fino a che il led rosso si spegne. PASSEGGERO CONNESSIONE: NON FARE NIENTE, attendere la connessione dall’altro casco, dopodiché il led rosso si spegne. I caschi adesso sono pronti per essere usati in modalità...
  • Page 20 Inizio / Fine Intercom Con entrambi i dispositivi accesi, premere su uno dei due dispositivi il pulsante PMF per avviare o terminare l’intercom. Comandi vocali Ruotare il PMF 2 volte in senso orario. Ricomposizione ultimo numero Ruotare il pulsante PMF due volte in senso antiorario. Rispondi a una chiamata Quando il telefono squilla, premere il pulsante PMF per rispondere alla chiamata o il sistema risponderà...
  • Page 21 Riproduzione / pausa della musica Fare doppio clic sul pulsante PMF per riprodurre o mettere in pausa la musica. Nota: non tutti i telefoni supportano questa funzione. Canzone precedente o successiva Canzone precedente: ruotare il pulsante PMF in senso orario e tenerlo in posizione per circa 1 secondo, quindi il pulsante andrà...
  • Page 22 Controllo della batteria Accendi il dispositivo, ruota il pulsante PMF e tienilo in posizione per 1 secondo, sentirai negli auricolari il livello della batteria. Avviso batteria scarica Quando la batteria è scarica, il LED rosso lampeggerà ogni 5 secondi e si sentirà un messaggio vocale che dice “BATTERY LOW”.
  • Page 23 NOTES:...
  • Page 24 H&H SPORTS PROTECTION S.R.L. Via Provinciale Lucchese 599/E Serravalle Pistoiese (PT) 51030 ITALY...
