SEVROLL SEVROLLBOX SLIM Quick Start Manual

FURNITURE ACCESSORIES
Drawer front Set for the internal drawer SEVROLLBOX SLIM

Components:

Drawer SEVROLLBOX SLIM
h = 84 mm / h = 167 mm / h = 199 mm
Length: 270
Set for internal drawer
SEVROLLBOX SLIM h = 84 mm
R
114
4x20
Screws for "drawer front base profile"
M3x7
Screws for "Set for internal drawer"
L W
LW – internal width of carcass
NL – nominal length of the drawer
minimum carcass length: (NL + 3 mm)
Drawer with flush front
The front of the drawer sits level with the carcass edges
Universal drawer front base profile for
internal drawer SEVROLLBOX SLIM
[mm]
300
350
400
450
500
550
Set for internal drawer
SEVROLLBOX SLIM h = 167 mm
L R

Cutting dimensions of profiles

NL : 270 [mm]
Universal drawer front base profile
300
350
400
450
500
550

Mounting dimensions

37 mm
1080
115
L
196
4x20
Screws for "drawer front
base profile"
M3x7
Screws for "Set for
internal drawer"
L = LW - 100 mm
P

Calculations for the back wall and base of the drawer

can be found in the instructions SEVROLLBOX SLIM
minimum carcass length: (NL + 12 mm)
Drawer with inset front
ATTENTION! To ensure that the drawers cover the high front applied,
the guides should be taken back by 9 mm (one hole in the guide)
Universal drawer front railing for internal
drawer SEVROLLBOX SLIM
1200
Only for use with SEVROLLBOX SLIM
h = 167 mm and h = 199 mm
Set for internal drawer
SEVROLLBOX SLIM h = 199 mm
R
228
4x20
Screws for "drawer front
base profile"
M3x7
Screws for "Set for
internal drawer"
Universal drawer front railing
L = LW - 87 mm
R
37 mm
9 mm
into the carcass
11
20
L
