INSTRUCTIONS
TM PATIO LOCKSET INSTALLATION INSTRUCTIONS
1
2
3
8
www.simplyelegantproducts.com
(Page 1 of 3)
4
5
6
7
13
12
11
22
9
10
21
13
17
18 19
20
1
Outside Key Cylinder
2
Key Cylinder Cover Plate (Escutcheon)
3
Adjustable Deadbolt
4
Thumb Turn Mounting Plate
5
2" Pan Head Screws (Two)
23
16
14
6
Thumb Turn and Cover Plate
7
1/2" Oval Head Screws (Two)
8
Outside Handle Assembly
9
Adjustable Spring Latch
10
Handle Spindle
11
Deadbolt Strike
12
2 1/2" Wood Screws (Two)
13
1/2" Wood Screws (Two)
15
14
Inside Lever Handle
15
Handle Mounting Plate and Cover Plate
16
Plastic Washer
17
Thread Washer
18
2 1/2" Flat Head Screw
19
Screw Cover
20
Latch Plate
21
Handle Spindle Collar
22
1 1/2" Flat Head Screws (Two)
23
Handle Cover Plate
TM Patio Lockset
070-117
070-118
070-119
070-120
1
Advertisement
Table of Contents
Related Manuals for Simply Elegant TM Patio Lockset
Summary of Contents for Simply Elegant TM Patio Lockset
- Page 1 TM Patio Lockset 070-117 070-118 070-119 070-120 INSTRUCTIONS (Page 1 of 3) TM PATIO LOCKSET INSTALLATION INSTRUCTIONS Outside Key Cylinder Key Cylinder Cover Plate (Escutcheon) Adjustable Deadbolt Thumb Turn Mounting Plate 2” Pan Head Screws (Two) Thumb Turn and Cover Plate 1/2”...
- Page 2 TM Patio Lockset 070-117 070-118 070-119 070-120 INSTRUCTIONS (Page 2 of 3) • The deadbolt is adjustable. It is set for 2 3/8” set back, DEADBOLT INSTALLATION but can be adjusted to 2 3/4”. (See the instruction sheet, “Adjustable Deadbolt & Latch.”) • The #3...
- Page 3 TM Patio Lockset 070-117 070-118 070-119 070-120 INSTRUCTIONS (Page 3 of 3) • Locate the tread hole for the bottom of #8 OUTSIDE HANDLE HANDLE INSTALLATION ASSEMBLY by measuring from the center of the bottom hole 7 1/2”. Then drill a 5/16” hole through the active door.
