Romans Moped Assembly Instructions
I f y o u h a v e n o m e c h a n i c a l e x p e r i e n c e , p l e a s e
h a v e t h e u n i t p r o f e s s i o n a l l y a s s e m b l e d .
Tools needed: #2 Phillips Screwdriver, 14mm Socket, 12mm Socket,
10mm Socket, 14mm Wrench, Crescent Wrench, Hammer, Allen
Wrench, Heavy duty Scissors or Utility Knife.
Cut straps off with heavy duty scissors or utility
knife.
Remove top from box
Tilt the box to the rear end of the moped and
remove
Cut ties holding the bag with scissors or utility
knife
Using a 14 mm socket, remove the bolts holding
together the shipping frame
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for BMS Romans
Summary of Contents for BMS Romans
- Page 1 Romans Moped Assembly Instructions I f y o u h a v e n o m e c h a n i c a l e x p e r i e n c e , p l e a s e h a v e t h e u n i t p r o f e s s i o n a l l y a s s e m b l e d .
- Page 2 Cut the zip tie holding the bag together using the heavy duty scissors or utility knife Remove the front wheel and trunk from the unit. Turn the key to the right to unlock the seat Open the battery box and remove the contents.
- Page 3 Remove Six Hole Funnel from plastic wrap and place into holes on top of the battery Attach Sulfuric Acid container to the tubes in the Six Hole Funnel Let Sulfuric Acid drain completely into battery Remove Six Hole Funnel and cap battery holes with the battery hole plug strip.
- Page 4 Insert battery nut and bolt into battery terminal Remove the front screw under the headlight assembly using a Phillips screwdriver Gently remove the front cowling assembly Slide the handlebar column over the steering shaft. Line up the hole for the screw with the hole in the column Insert the bolt and tighten using a 14 mm socket and 14 mm wrench...
- Page 5 Remove the bolt holding the front forks to the frame. Do not discard the bolt and nut. Remove the spacer from between the front brake pads Insert the bearing sleeve into the wheel on the side with the brake rotor. Place the spacer between the brake rotor assembly hole and the fork.
- Page 6 Insert the bolt removed earlier from the forks into the front wheel assembly from the side without the brake rotor and tighten. Cut the wires holding the unit to the frame and put the unit on the main kick stand. Remove the bolts from the rear body just below the seat.
- Page 7 Using the silver screws attach the front cowling to the body Screw the wing mirrors into the handlebars. Tighten the screw cap securely using a crescent wrench Locate the battery compartment in the center of the floor and open using Phillips head screwdriver...
- Page 8 Connect the MAIN RED WIRE and RED WIRE with FUSE to the RED TERMINAL on the battery. Connect the MAIN GREEN WIRE to the BLACK TERMINAL on the battery Replace the cover and screw down using Phillips head screwdriver. Place the floor guard over the floor and attach to the floor.
- Page 9 NOTE** that 2 of the screws are closest to the part of the trunk farthest from the key. Place the black plastic adapter plate onto the bottom of the trunk with the square side closest to the key end of the trunk Attach one of the brackets to the lower side and slip a washer, locking...
- Page 10 Finish...
