TECHNICAL DOCUMENT
?
LOOKING FOR A VIDEO?
Before you begin, select the image below to watch a
walk-through video of this entire installation procedure.
1.1 PURPOSE
This document gives instructions on installing the ECM1v1.5 Update
Kit on a mill.

1.2 PRODUCT INFORMATION

Product: ECM1v1.5 Update Kit (PN 39257)
Quantity
1 3 A Fuse (PN 31120)
1 10-Pin Terminal Block (PN 32632)
1 Crimp Cap (PN 38453)
1 ECM v1.5 Board (PN 37509)
1 ECM v1.5 Protective Cover (PN 37518)
8 Nylon Standoff (PN 38688)
1 Return Shipping Label
3 Wires 443-445 (PN 35667)
©Tormach® 2020
Specifications subject to change without notice.
Description
Note: If any items are missing, we can help. Email
support@tormach.com to contact Tormach Technical
Support for guidance on how to proceed.

1.3 REQUIRED TOOLS

This procedure requires the following tools. Collect them before you
begin.
Flat-blade screwdriver
l
Flat-blade screwdriver, small
l
Phillips screwdriver
l
Wire crimper (or similar)
l
Page 2
TD10571: Installation Guide: ECMv1.5 Update Kit (0420A)
